Specifications
Brand Name :
ZTZG
Model Number :
DSS120
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets/year
Delivery Time :
90 days
Packaging Details :
All mechanical equipment is nude packing and electrical parts are packed in wooden cases
Product Name :
Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill
Condition :
New
Type :
Pipe Production Line
Pipe size :
60mm×60mm-130mm×130mm
Thickness :
1.2-6.0mm
Pipe Shape :
square rectangular
Raw material :
Q235 Steel
Voltage :
220/380/415/420/440V
Color :
Grey or as your require
Warranty :
One Year
After-sales Service Provided :
Engineers available to service machinery overseas
Description

Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill

Direct Square to Square Pipe Mill Introduction:

It is directly roll the steel strip and bend it to square & rectangular shape, then weld it to finish the formation.

Direct Square to Square Pipe Mill Characteristics and Advantages:

1) Compare with round into square & rectangle forming way, this way is better for the shape at the edge of cross section, comparatively, semidiameter of inner arc is Small, and the brim is flat, outlook is regular.
2) the whole line load is low, especially the sizing parts.
3) It adapt the combined type roller on the most of the stands, it realize that one set of roller can produce dozens of square & rectangle pipe with different specification, it decrease the store of roller, low the cost about 80% on roller, Fast the bankroll turnover, short the time one new product design.

Production Process


Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill

Square Tube Mill Product Parameter:

Product & yieldSquare & rectangle tube60mm×60mm-130mm×130mm Thickness:1.2mm-6.0mm
Length6m-12m Length Tolerance:±3mm
Production Speed50-120 m/min
Production Capacity30000ton/year
ConsumptionMill Installed Capacity220kw
Line Area85m(length)×7m(width)
Worker6-8 workers
Raw MaterialCarbon Steel CoilCarbon steel coil Q235B(ASTM GR·D,σs 230)
Width240mm-520mm Thickness:1.2mm-6.0mm
Coil ID580-700mm
Coil ODMax 2000mm
Coil Weight30.0t

Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill
Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill
Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill
Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill
Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube MillGalvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill
Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube MillGalvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill
Galvanized Steel Pipe Energy Supply Pipe Long Service Life Square Tube Mill

FAQ:
Q:Are you manufacturer?
A:Yes,we are manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and
Moulding ). We also have our own R&D department. Welcome to visit us.
Q:What kind of payment term do you do?
A: We do T/T and L/C.
Q:What info do you need before giving me the price and proposal?
A: Since we design individual machine based on our customer's requirement, we need your desired
products' basic dimension, including all the pipe diameter(or tube length), thickness range , usage,
raw material steel grade, coil weight, and degree of automation.
Q: What should I do if I just start a new business?
A:Contact us immediately ,we provide free consultant for pre-sales service .Also we can help you
solve the raw material (steel coil) purchase, worker training, international market price, and more.
Q:How do you do QA?
A:We have special team to do strict QA,this is one of our strengths:
(1)Every gear box will be tested for 8 hours with oil inside to guarantee there is no leak.
(2)Every shaft will be inspected for the centering jumpiness.
(3)Every roller will be checked to make sure its in the range of tolerance critical parts will be
inspected for all dimensions.
Q:Why I should choose you? what are the differences between you and other Chinese suppliers?
A:We are concentrate on pipe making machines for more than 20 years. We have constructed many
steady trading partners in Asia,Africa, middle east, Europe, and South America throughout the years.
Our innovative designed production line and each single unit of the production line are not only
economical but also practical.
