200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding
200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding
200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding
200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding
200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding
200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding
Specifications
Brand Name :
ZTZG
Model Number :
ERW 127
Certification :
ISO9001 SGS CE
Place of Origin :
China Hebei Shijiazhuang
MOQ :
1set
Price :
Negotiatable
Payment Terms :
T/T, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100Set/year
Delivery Time :
135 days
Packaging Details :
1.The electric controlling box is packed by protect film 2.All the spare parts are put in the wooden box
Application :
Furniture
Name :
ERW 127 pipe making machine
Outer Diamete :
48-127mm
Thickness :
1.0-4.0mm
Square pipe :
40x40mm-100mx100mm
Speed :
20-90m/min
Pipe length :
4-12mm
Driving Motor :
200kw
Material of Pipe :
ST37 ST52
Voltage :
customer
color :
Any colour
Marketing Type :
New product 2021
Power :
550kw
Description

High Frequency Straight Seam Welding Diameter 76 MM Round Square Steel Pipe Production Line

General Description

ERW76 high frequency longitudinal welded pipe production line / pipe making machine / tube mill is designed to produce welded pipes of 32mm-76mm in OD and 1.2mm-4.0mm in wall thickness, as well as corresponding square and rectangular pipe.

Base condition

Steel Pipe Specification

Round Pipe diameter

Φ32–Φ76mm

Pipe Thickness

1.0 – 4.0mm

Square and rectangle pipe2

20x20– 60x60mm

Pipe Thickness

1.0 – 3.0mm

Pipe Length

6-12m

Length Tolerance

±6 mm

Steel Tape Specification

Material

Carbon steel (δb≤500Mpa, δs≤235Mpa)

Inner diameter

Φ470-Φ510mm

Outer diameter

Φmax=1800mm

Strip steel width

 80-240mm

Strip steel thickness

1.2mm-4.0mm

The maximum weight

4.0 tons

Electric installed capacity

appro.500KW

Line Speed

1.5m3/h

The technical flow of the production line:

Scrolling up→ Uncoiling → Shear and Welding→ Spiral accumulator→ Forming → H.F. induction welding→ External burr removing→ Cooling → Sizing→ Flying saw → Run out table →Inspecting→ Packing→ Warehouse

200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding

200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding200kw Diameter 76MM Round Steel Pipe Production Line High Frequency Welding

FAQ

Q: Are you a manufacturer?
A: Yes, we are a manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and Moulding ). We also have our own R&D department. Welcome to visit us.
Q: What kind of payment term do you do?
A: We do T/T and L/C.
Q: What info do you need before giving me the price and proposal?
A: Since we design individual machines based on our customer's requirements, we need your desired products' basic dimensions, including all the pipe diameter(or tube length), thickness range, usage, raw material steel grade, coil weight, and degree of automation.
Q: What should I do if I just start a new business?
A: Contact us immediately, we provide a free consultant for pre-sales service. Also, we can help you solve the raw material (steel coil) purchase, worker training, international market price, and more.
Q: How do you do QA?
A: We have a special team to do strict QA, this is one of our strengths:
(1)Every gearbox will be tested for 8 hours with oil inside to guarantee there is no leak.

(2)Every shaft will be inspected for centering jumpiness.
(3)Every roller will be checked to make sure it's in the range of tolerance critical parts will be inspected for all dimensions.
Q: Why I should choose you? what are the differences between you and other Chinese suppliers?
A: We are concentrating on pipe-making machines for more than 20 years. We have constructed many steady trading partners in Asia, Africa, the Middle East, Europe, and South America throughout the years.
ur, innovatively designed production line and every single unit of the production line are economical and practical.
