Specifications
Brand Name :
ZTZG
Model Number :
ZJ1250
Certification :
CE, SGS, ISO9001
Place of Origin :
China
MOQ :
1Set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
120 Set Per Year
Delivery Time :
120 Days
Packaging Details :
All mechanical equipment is nude packing and electrical parts are packed in wooden cases.
Name :
Metal steel slitting machine, automatic cut to length line for sheet materials steel
Raw material :
Galvanized steel,PPGI/GI/low carbon steel
Coil width :
900-1250mm
Thickness :
0.5-2mm
Application :
Slitting,steel coiler,steel coil cutting to length
Operate style :
Automatic
After-sales service provided :
Engineers available to service machinery overseas,field installation,commissioning and training,video technical support
Color :
Any Color
Warranty :
1 Year
Line speed :
50-90m/min
Feeding width :
As customers requirement
Description

High Precision Slitting Line Machine Striped Steel Cutting Device Steel Coil Slitting Machine

Products Description

Slitting line is used to slit wide steel strip into certain width and then recoil them to meet the request of various procedure for welded pipe and cold rolled section steel production.

According to the material slitting thickness there are thin plate or board slitting machine,media-thickness plate or board slitting machine and thick plate or board slitting machine. According to the metal materials there are copper strips slitting machine,stainless steel slitting machine,cold or hot rolled plate slitting machine,silicone steel slitting machine.

Application

It is suitable for the longitudinal shearing of the metal coils and rewinding coils.

Advantages

Easy to operate, slitting quality is high, excellent material utilization, Stepless shearing speed regulation, etc.

Structure

It consist of uncoiler, feeding and positioning, slitting unit, recoiler, etc.

1. Coil car
2. Decoiler
3. Leveler with entry pinch roll for cut to length line system
4. Measuring Roller for cut to length line system
5. Mechanical side guide
6. Hydraulic shearing machine for the cut to length line system
7. Lifting table for stacking in the entry loop for the cut to length line system
8. Mechanical side guide and guide roll
9. Slitter head 10. Scrap winder
11. Loop table
12. Strip separator and tension unit
13. Deflector roll and exit threading table
14. Recoiler with push off plate& outboard bearing support
15. Over arm separator in the recoiler.
16. Exit coil car
17. Hydraulic Systems
18. Pneumatic Systems
19. Electric Systems

Production Process


Loading Coil → Uncoiling → Leveling → Cutting the Head and End → Circle Shear → Slitter Edge Recoiling → Accumulator → Steel Head and End Bending → Separating → Tensioner → Coiling Machine

Thickness 0.5-2mm Steel Strip Cutting Machine High Precision Slitting Machine 90m/min

Product Parameter

Steel
coil parameters		 Material Cold rolled sheets and GI sheets
Tensile strength Tensile strengthδb≤500Mpa,
Yield strength δS≤235Mpa
Steel thickness 0.5-2mm
Steel width 900-1250mm
Steel coil weight 15T
Slit parameter Max slit quantity 10 pcs (0.5mm) 7 pcs (2mm)
Width precision ±0.05mm
Other parameters Line speed 50-90m/min
Operator needed 1 mechanical engineer +2 common workers
Line direction Customer’s request
Machine color Customer’s request

Model List

No. Model Roll Width(mm) Thickness(mm) Cutting Speed(m/min)
1 ZJ1000 500-1000 0.18-1.5 80-100
2 ZJ1250 900-1250 0.5-2 50-90
3 ZJ1500 1000-1500 1.8-4 40-80
4 ZJ1600 1000-1600 2-6 30-70
5 ZJ1600 1000-1600 4-10 20-70
6 ZJ1600 1000-1600 4-12.7 20-60
7 ZJ1800 1000-1800 5-14 15-60
8 ZJ2000 1200-2000 6-16 12-50

Note: We can design and manufacture slitting machine according to customers' requirements.
