Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Specifications
Brand Name :
ZTZG
Model Number :
1600x4
Certification :
ISO9001
Place of Origin :
Hebei, China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200 sets/year
Delivery Time :
120 days
Packaging Details :
All mechanical equipment is nude packing and electrical parts are packed in wooden cases
Material :
Low carbon steel
Strip thickness :
0.4- 8.0mm
Strip width :
600～1600mm
Camber on strips :
0.3mm/m
Color :
Chosen by cutomer
Warranty :
1 year
Voltage :
220V/380V
Cutting Speed :
3 - 8 mm
No. of Slitting Lines :
10
Coil Weight (T) :
10 T
Condition :
New
Rated Power :
15kw
Dimension(L*W*H) :
11000*1500*1800
No. of Slitting pieces :
10
Certification: :
ISO9001
Key Selling Points: :
Easy to Operate
After-sales Service Provided: :
Field installation, commissioning and training, Field maintenance and repair service, Online support, Free spare parts, Video technical support, Engineers available to service machinery overseas
After Warranty Service: :
Video technical support, Online support, Spare parts, Field maintenance and repair service
After-sales service provided :
Engineers available to service machinery overseas
Name :
Aluminium Steel Sheet Coil Slitting Making Machine
Thickness :
0.2-1.2mm
Description

Slitter Line Machine With Recoiler Production Line Steel Coil Slitting Machine Steel Slitting Machine

Slitting line description
Slitting machine used to uncoil, slitting, rewinding the metal coil into the desired width of the strip. It is suitable for cold and hot rolled carbon steel, silicon steel, tinplate, stainless steel and all kinds of metal materials after surface coating.

Main Parameters

1. Feed material Steel plate
2. Feeding thickness 0.2mm - 0.35mm
3. Feeding width 300 mm-1300 mm
4. The largest material roll ￠ 1200 mm
5. Inner diameter of material roll Customer provided
6. Roll weight 5T


Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine

Theory
Coil-loading — Single-mandrel uncoiler — Coil-head-feeding, press & shoveling — Double-roller pinch feeding, three-roller leveling — End-cutting — Hole Accumulator(1) — Strip-aligning — Disc shearing — Scrap reeling — Hole Accumulator(2) — Pre-separator/Tensioner/length-measuring roller — Recoiling/Coils press & separator — Coils-discharging — Hydraulic control — Electric contro

Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Specialized in the manufacture of material cutting, cutting machinery and its ancillary machinery and equipment
Many years engaged in the scissors, sleeve, cutting, cutting machinery manufacturing experience
Scatter machine manufacturing speed is fast

Inspection
The accuracy and capability of the slitting line:

1～1.5mm ±0.15mm 20pcs
1.6～3.0mm ±0.15mm 15pcs
3.1～4mm ±0.15mm 10pcs
Camber on strips:0.3mm/m

ZTZG Company Introduction
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine
Easy Operate 8.0mm Thick Steel Slitting Line , Metal Coil Slitting Machine

FAQ

Q: Are you a manufacturer?
A: Yes, we are a manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and Moulding ). We also have our own R&D department. Welcome to visit us.
Q: What kind of payment term do you do?
A: We do T/T.
Q: What info do you need before giving me the price and proposal?
A: Since we design individual machines based on our customer's requirements, we need your desired products' basic dimensions, including all the pipe diameter(or tube length), thickness range, usage, raw material steel grade, coil weight, and degree of automation.
Q: What should I do if I just start a new business?
A: Contact us immediately, we provide a free consultant for pre-sales service. Also, we can help you solve the raw material (steel coil) purchase, worker training, international market price, and more.
Q: How do you do QA?
A: We have a special team to do strict QA, this is one of our strengths:
(1)Every gearbox will be tested for 8 hours with oil inside to guarantee there is no leak.

(2)Every shaft will be inspected for centering jumpiness.
(3)Every roller will be checked to make sure it's in the range of tolerance critical parts will be inspected for all dimensions.
Q: Why I should choose you? what are the differences between you and other Chinese suppliers?
A: We are concentrating on pipe-making machines for more than 20 years. We have constructed many steady trading partners in Asia, Africa, the middle east, Europe, and South America throughout the years. Our innovative designed production line and every single unit of the production line are economical and practical.
