24KV 20_40/5A LZZBJ9-20/24 medium voltage current transformer CT
24KV 20_40/5A LZZBJ9-20/24 medium voltage current transformer CT
24KV 20_40/5A LZZBJ9-20/24 medium voltage current transformer CT
24KV 20_40/5A LZZBJ9-20/24 medium voltage current transformer CT
Specifications
Place of Origin :
Zhejiang, China
Brand Name :
CHONNER
Model Number :
LZZBJ9-20/24
Phase :
Single
Coil Number :
AUTOTRANSFORMER
Usage :
Power
Coil Structure :
TOROIDAL
Voltage :
24KV
Color :
Brown
Product name :
24KV current transformer
Frequency :
50HZ
Current ratio :
20_40/5
Model :
LZZBJ9-20/24
Packaging Details :
1PCS per wooden carton
Port :
NINGBO
Supply Ability :
500 Piece/Pieces per Month
Price :
$220.00/Pieces >=1 Pieces
Description

24KV 20_40/5A LZZBJ9-20/24 medium voltage current transformer CT

Techanical sheet as below:

20_40/5A, VA:15 24KV, 50HZ, CL:0.5, Bornes: (S1_S2:20/5A) (S1_S3:40/5A), Guarantee: 1year

1
Highest voltage for equipment
12 - 36 kV
2
Rated frequency
50 / 60 Hz
3
Rated primary current
20 - 5000 A
4
Rated secondary current
1 / 5 A
5
Rated transformation ratio
e.g.: 100/5 A
6
Rated output
2.5 / 5.0 / 10 / 15 / 20 / 25 / 30 / 40 / 50 VA
7
Accuracy class for measurement
0.1 / 0.2 / 0.5 / 1 / 3 / 5 / 0.2S / 0.5S
8
Accuracy class for protection
5P / 10P
9
Rated short-time thermal current
8 - 50 kA×1s
10
Rated dynamic current
20 - 150 kA

24KV 20_40/5A LZZBJ9-20/24 medium voltage current transformer CT
