Specifications
Brand Name :
Shunda
Model Number :
SMD-90
Certification :
FDA
Place of Origin :
China
MOQ :
1 SET
Price :
negotiation
Payment Terms :
T/T or L/C
Supply Ability :
100 SETS per month
Delivery Time :
25 working days after received your payment
Packaging Details :
Export wood case,20ft can load 2 sets of machine
Product Name :
paper tea cup making machine
Speed :
100-160pcs/min
Output :
380/220V
MATERIAL :
135-450GRAM
Eletricity Board :
Ultrasonic heating
Description

Custom Disposable Paper Cup Production Machine , 5oz / 7oz / 10oz Paper Cup Making Plant

Product advantage :


1. Danfos Transducer
2. 125’ diving box
3. Photoelectric tracking
4. Electricity box and machine are separate.

Specifications:

Model SMD-90
Capacity pcs/min 100-120 90-110 80-100
Size Range mm(max) Top diameter:90
Bottom Diameter:80
Height:140
Top diameter:110
Bottom Diameter:80
Height:170
Top diameter:125
Bottom Diameter:100
Height:170
Suitable Paper Thickness gsm 135-450
Sealing Method Ultrasonic and hot air system
Running Power KW 10 11 12
Air compressor 0.4m²/Min. 0.5MPa 0.5m²/Min. 0.5MPa 0.6m²/Min. 0.5MPa
Net weight Kgs 3400 3500 3600
Machine dimension mm 2500*1800*1700 2600*1800*1800 2700*1800*1800
Collector Dimension mm 900*900*1760 1000*900*1860 1100*900*1860

Description:

ZBJ-9A INCLUDS DELIVER PAPER (PRINTED AND CUTED PAPER FAN), SEAL(HEATING), OIL INDECTION, BOTTOM CUT, HEAT,BOTTOM SEALING, HEMMING AND CUP DISCHARGE ,ALSO , IT HAS PHOTOELECTRIC CONTROL, SHORT CIRCLE PROTECTION,AND AUTOMATICALLY COUNTING. IT PRDODUCE COLD AND HOT DRINNK CUP , TEA PAPER CUP, COFFEE PAPER CUP,ICE CREAM PAPER CUP. ONE PERSON EASY OPERATION, STABLE PERFORMANCE, LESS PLACE, HIGH EFFICIENCY .

Advantages

Machine size is small,can operate more easy

Custom Disposable Paper Cup Production Machine , 5oz / 7oz / 10oz Paper Cup Making Plant

Cup Size

Custom Disposable Paper Cup Production Machine , 5oz / 7oz / 10oz Paper Cup Making Plant

Our QC team

A QC team with more than 10 professional and technical personnel. To ensure 100% products checking.
Material: Strictly control of material using, meet international requested standards.
Semi-finished products inspection: Product inspection before 100% finished.
Production line test: With work team or data engineer who will inspect machines and lines at fixed period.
Finished Product Inspection: Quality and property test before products are packed and loaded.

FAQ

1. Q: Is your company a factory or trading company?

A: Our company is a factory.

2. Q: How does your factory do regarding quality control?

A: Quality is priority. Shunda people always attach great importance to quality controlling from the very beginning to the very end: 1). All raw material we used are environmental-friendly; 2). Skilful workers care every details in handling the producing and packing processes; 3). Quality Control Department specially responsible for quality checking in each process.

3.Q: Do you have Guiding Box or CD video for clients?

A: Yes,we have,we will send guiding box with CD together to clients.
