High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System
High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System
High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System
High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System
High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System
High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System
Specifications
Brand Name :
Shunda
Model Number :
SMD-90
Certification :
CE201090502/CE
Place of Origin :
China
MOQ :
1 set
Price :
$ 450000-60000 USD/SET
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
15 set per mouth
Delivery Time :
25-35 working days
Packaging Details :
Wooden Pallet for paper cup making machine
Speed :
90-100 pcs/min
Material :
Single or double PE coated paper
Color :
white
Cup Range :
< 16 oz
Heating System :
Switzerland Hot Air System
Air Compressor :
0.5M^3/min
Product Output :
380V,16 KW,50HZ, Three Phase four wire
Machine Size :
2500×1800×1700mm
Counter Size :
900×900×1760 mm
Weight :
3.5 tons
Description

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

Advantage for paper cup machine SMD-90

1.Open cylindrical indexing gear

2.Switzerland Hot air sealing device

3.Mitsubishi PLC tracking and Touch screen Controlling cabinet

4.Servo-driven bottom-web feed(Brand:Taiwan DONGYUAN)

5.Automatic oil-spray lubrication system

6.Infinitely variable drive

7.Safety Door opening protection device

8.Photoelectric tracking and detecting every step

9.Automatic collecting and counting system

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

Technology Specification

Model SMD-90
Capacity pcs/min 100-120 90-110 80-100
Size Range mm(max) Top diameter:90
Bottom Diameter:80
Height:140		 Top diameter:110
Bottom Diameter:80
Height:170		 Top diameter:125
Bottom Diameter:100
Height:170
Suitable Paper Thickness gsm 135-450
Sealing Method Ultrasonic and hot air system
Running Power KW 10 11 12
Air compressor 0.4m²/Min. 0.5MPa 0.5m²/Min. 0.5MPa 0.6m²/Min. 0.5MPa
Net weight Kgs 3400 3500 3600
Machine dimension mm 2500*1800*1700 2600*1800*1800 2700*1800*1800
Collector Dimension mm 900*900*1760 1000*900*1860 1100*900*1860

Machine Running Video

http://www.youtube.com/watch?v=OX6v6k-0sLo&feature=youtu.be

Market

High Speed Automatic Disposable Coffee Cups Making Machine Hot Air System

Advantages

  1. Quality assurance both for our products and service for after-sales.
  2. Favorable price.
  3. Great variety of products.
  4. Attractive design
  5. Environment Friendly Technology
  6. OEM and ODM service provided

Our QC team

A QC team with more than 10 professional and technical personnel. To ensure 100% products checking.
Material: Strictly control of material using, meet international requested standards.
Semi-finished products inspection: Product inspection before 100% finished.
Production line test: With work team or data engineer who will inspect machines and lines at fixed period.
Finished Product Inspection: Quality and property test before products are packed and loaded.
