Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
Specifications
Brand Name :
XINZHENG
Model Number :
D1C-H-A
Certification :
CE FDA ISO
Place of Origin :
china
MOQ :
1 - 1 Sets
Price :
$49,000.00
Payment Terms :
T/T WesternUnion Money Gram
Supply Ability :
10 Set/Sets per Month
Packaging Details :
1.clean Automatic coffee capsule filling sealing machine and Vegetable oil protect machine not rust 2.Stretch film packaging Automatic coffee capsule filling sealing machine 3.Wooden tray to support Automatic coffee capsule filling sealing machine
Condition :
New
After Warranty Service :
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location :
None
Showroom Location :
None
Voltage :
220/380V, 220V 380V
Warranty :
1 year
After-sales Service Provided :
Online support
Port :
Shanghai/Ningbo
Description

Four Lanes Dolce Gusto Coffee Capsule Filling Machine

1.Automatically accomplish all production process,small volume,operate easily.

2.PLC control system and full display and real-time monitoring.

3.Automatically load cup.

4.Automatically vacuum suck and convey materials.

5.Servo control auger filling.

6.Filling liquid system(various flavor)

7.Automatically suck capsule rim remaining powder.

8.UV germicidal lamp(option)

9.Automatically suck and place lid.

10.Filling nitrogen system,nitrogen flush process from empty capsule to heat seal station.

11.Automatically heat seal,line seal and flat seal.

12.Automatically output finished products.

13.Automatically reject unqualified product.

14.Automatically count capsule quantity on conveyor belt;Sensor detect empty cups loading position,no cups and alarm.

15.No cup,no filling,no seal,if empty cup in the mould,automatically start reject function,recycle it.

16.Automatically detect lids quantity,below a certain position,alarm and inform add lids.

17.Machine mainframe adopts food standard stainless steel.organic glass door design,beautiful appearance,high safety.

18.Automatically count finished products.

19.Failure tips display on the touchscreen.

Four Lanes Dolce Gusto Coffee Capsule Filling Machine Scope Of Application

The machine is suitable for various granule, powder and liquid materials. Such as coffee, milk powder, milk powder, tea, tea, instant powder, yogurt and other food materials.

Applicable capsule: Compatible Nespresso ,Dolce gusto, Lavazza blue or point,Pod,K-CUP,K-shot,One CUP

Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine

Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine

Four Lanes Dolce Gusto Coffee Capsule Filling Machine Parameter

Model DC-4
Filling weight range 0-20g(Option)
Filling accuracy ±0.15g
Speed 150-200Cups/per minute
Hopper capacity 10-24L/110L
Control system PLC
Displayer 10 inch Touchscreen
Power supply AC220V/380V 50Hz/60Hz 5KW
Dimension 5850(L)×4490(W)×2200(H)mm
Weight 1200kg
Gross weight 1500kg

Four Lanes Dolce Gusto Plc Coffee Capsule Filling Machine

Four Lanes Dolce Gusto Plc Coffee Capsule Filling MachineFour Lanes Dolce Gusto Plc Coffee Capsule Filling MachineFour Lanes Dolce Gusto Plc Coffee Capsule Filling Machine
