CR825 Multifunctional diesel fuel injection common rail test bench
CR825 Multifunctional diesel fuel injection common rail test bench
Specifications
Brand Name :
XBD
Model Number :
XBD-CR825
Certification :
CE & ISO
Place of Origin :
Shangdong
MOQ :
1 set
Price :
USD10000.00-15000.00 per set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60 sets per month
Delivery Time :
15-20 days
Packaging Details :
Plywood case
Product name :
diesel pump injection common rail test bench
Power :
Electronic
Warranty :
12 months
Voltage :
380V
Usage :
Test common rail system
Color :
Green
Packing :
Plywood case
Weight :
1100kgs
Description

CR825 Multifunctional diesel fuel injection common rail test bench

CR825 Multifunctional diesel fuel injection common rail test bench

The main function:

1. Test common rail injector

2. Test common rail pump

2. Test unit pump/pump nozzle

4. Test the HEU injector

5. Test the HUI actuator pump

6. Test the Carter 320D common rail pump

7. Maximum rail pressure 180-240 MPa

8. IQA code generation

9. Injection drive and system voltage monitor

10. Common rail with filtering function

11. Dual DRV configuration

12. High-voltage filter plugging reminder function

13. Oil tank and diesel mailbox integrated air conditioning strong refrigeration system

CR825 Multifunctional diesel fuel injection common rail test bench

Data of test bench

1 Supply voltage 380V AC, 220V AC (optional)
2 Phase 3 phase, single phase (optional)
3 Frequency 50Hz/60Hz
4 Current 25-45A (MAX)
5 Main motor power 11-22KW
6 Main motor speed range 0-4000RPM/MIN
7 Oil pump motor power/flow 0.19KW/10LMIN
8 Diesel pump motor power/flow 11KW/10LMIN
9 Control loop voltage DC12V/24V 350W
10 EUC internal boost 0-200V DC (MAX)
11 Oil tank volume 36L
12 Diesel fuel tank volume 45L
13 Oil temperature control method Heating/forced cooling
15 Flow meter (injection) 4-500ml/min
16 Flow meter (oil pump oil supply) 1-400L/H
17 Flow meter (oil) 5-600L/H
18 Motor and work surface center distance 125mm
19 Weight 1100kg
20 Appearance net size 2250*1280*1920mm
21 Package size 2350*1500*2100mm

Package

The package is wooden case or plywood case, if you need, we can also pack the products according to your demands.

CR825 Multifunctional diesel fuel injection common rail test bench

FAQ

Q: How many days to produce this test bench?

A: It need 5-20 days to produce the test bench.

Q:How can I pay for it?

A:We support TT payment, West Union, and L/C etc.

Q:How to sign an order?

A:We can sign an order offline or online on Ali.

Q:How long of warranty?

A:12 months

Q:Do you have some repairing tools?

A:Yes, we have many kinds of repairing tools for common rail injector and pump
