Working clothes washing machine
Working clothes washing machine
Working clothes washing machine
Working clothes washing machine
Specifications
Brand Name :
TONGYANG
Model Number :
XTQ-30
Certification :
ISO9001 CE
Place of Origin :
china tongjiang
MOQ :
1
Price :
6500 USD
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
5-8 works day
Packaging Details :
wooden
Description

Working clothes washing machine,Main Feature
1. Touch and big screen with multi-language adopted, the whole course of pre-washing, sterilizing, rinsing, bleaching and extracting can be finished automatically.
2. Equipped with inverter, the machine has the advantages of energy saving and stable running. For high extraction, there are four speeds available depending on different materials.
3. It has a through drum without barrier. It is easy for operator to make loading and unloading. Opening, closing, tilting and unloading are performed automatically.
4. All control valves are pneumatically controlled so that the action is quick and stable. Double-pipe rear drainage structure, there is no pollution to the environment.
5. The machine is of high rust resistance and long service life as a result of the top quality of stainless steel.

Working clothes washing machine

Model NO.: XTQ Series
Automatic Grade: Automatic
Roller Fixing Type: Submerged Floating
Fuel: Steam or Electrical Heating
Capacity: From 15kg to 100kg
Certificates: ISO CE
Transport Package: With Wooden Box
Origin: China
Washing Capacity: From 15kg to 100kg
Type: Vertical
Brand: Tongyang
Material: All Stainless Steel 202 or 304 or 316 Grade
Automation Degree: Automatic-Fully Washing Machine
Trademark: Tongyang
Specification: CE, ISO9001
HS Code: 8451400000

With CE and ISO9001 certificates.

Model XTQ-15H XTQ-20H XTQ-30H XTQ-50H XTQ-70H XTQ-100H
Rated capacity (kg) 10-15kg 15-20kg 20-30kg 35-50kg 50-70kg 70-100kg
Motor power (kw) 2.2kw 2.2kw 4.0kw 5.5kw 7.5kw 7.5kw
Electrical power(kw) 12kw 15kw 24kw 36kw -- --
Roller dimension (mm) 650mm 673mm 902mm 1060mm 1200mm 1200mm
Roller deep (mm) 450mm 550mm 500mm 605mm 626mm 815mm
Roller volume 149Lit 195Lit 320Lit 504Lit 708Lit 920Lit
Average speed (r/min) 90r/min 90r/min 72r/min 75r/min 70r/min 65r/min
Washing speed (r/min) 50r/min 45r/min 36r/min 35r/min 33r/min 31r/min
Middle dewater speed (r/min) 450r/min 400r/min 420r/min 380r/min 350r/min 310r/min
High dewater speed
(r/min)		 890r/min 820r/min 780r/min 760r/min 680r/min 680r/min
Steam pipe 3/4" 3/4'' 1" 1" 1" 1"
Cold water pipe 3/4" 3/4'' 3/2" 3/2" 3/2" 3/2"
Hot water pipe 3/4" 3/4'' 3/2" 3/2" 3/2" 3/2"
Drain valve φ70mm φ70mm φ140mm φ140mm φ140mm φ140mm
Power supply Standard :380+N-3PH-50HZ
Overall size
(length*width*height) mm		 1010*1110
*1510		 1100*1020
*1500		 1410*1430
*1760		 1650*1750
*1900		 1850*1800
*2300		 1850*2000
*2300
Weight (kg) 950kg 980kg 1900kg 2600kg 2800kg 3130kg
