DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
Specifications
Place of Origin :
Shandong Province, China
Brand Name :
SH
Model Number :
DS2000, DS1300, DS700
MOQ :
1 SET Portable swing blade sawmill
Price :
US $6,700 - 14,800 / Set
Packaging Details :
container loading
Delivery Time :
within 15 days
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
500sets/year
Certification :
ISO9001
Name :
Portable swing blade sawmill for timber cutting
Condition :
New
Type :
Circular saw
Max. sawing timber size :
300x210mm, 210x210mm, 150x150mm
Sawing wood length :
6meters or as customer needs
Controlling system :
PLC automacit control
Feeding :
Inverter
Main motor :
22kw, 15kw, 11kw x 2sets
Voltage :
380v,3phase,50hz or as customer needs
Warranty :
12 months
Description

DS2000 Wood Circular Blade Saw mill Portable Swing Blade Sawmill with big motors power

Double Blades Angle Circular Saw Mill

  • The Sawmill is a versatile machine for the radial lumber, Pooh flooring material,carpenter lumber and palette lath production.
  • The Blades enables cutting in both directions,which considerably increases the cutting capacity.
  • Quick and accurate electronic positioning guarantee invariable high productivity and safety.
  • The angle circular saw is a machine that:
  • Produces lumber with saw-cut dimension accuracy up to ± 1mm
  • Produces lumber of excellent surface quality
  • Results in very low operational costs
  • Electric inverter crane,touch screen for length calculation and remote control.

Specification:

  • Max. sawing timber size : 300mm x 210mm
  • Carbide circular blade diameter : 760mm , 546mm
  • Log feeding : frequency auto feeding

Technical Parameter DS700 DS1300 DS2000
Max Sawing Wood Diameter 700MM 1300MM 2000MM
Max Sawing Wood Size 150*150MM 210 * 210MM 300*210MM
Saw Blade Diameter 2*424MM 2*546MM

1*760mm

1*546mm
Motors Power(KW) 11KW*2, 1.5KW*2, 2.2kw x 1

15KW*2, 1.5KW*1

2.2kw *1,3kw *1

22KW*1, 15KW*1

1.5KW*1 ,2.2kw *1

3kw *1
Max Swing Wood Length 6 Meters 6 Meters 6 Meters
Machine weight 1500KG 2000KG 3000KG

DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting MachineDS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine

Double Shaft Multi Blades Rip Saw

Multi Blades Rip Saw- For wood panels/plank cutting

Model
SH60-300
SH80-300
SH100-300
SH120-300
SH150-300
Max. Sawing width
250-300mm
250-300mm
250-300mm
250-300mm
250-300mm
Max. Sawing thickness
60mm
30-80mm
40-100mm
50-120mm
60-150mm
Motor
18.5KW/22KW
22KW*2
22KW*2
22KW*2
30KW*2
Saw Blade Diameter
150MM
180mm
210mm
230mm
255mm
Spindle Diameter
50mm
50mm
50mm
50mm
50mm
Weight
1190kg
1260kg
1420kg
1560kg
1620kg

Double Spindle Panel Cutting Multiple Blades Rip Saw -Heavy Duty Type

Model
SH100-400
SH120-400
SH160-400
SH200-400
SH250-400
SH270-400
SH290-400
Sawing width
350-400mm
350-400mm
350-400mm
350-400mm
350-400mm
350-400mm
350-400mm
Sawing thickness
40-100mm
50-120mm
70-160mm
90-200mm
110-250mm
130-270mm
150-290mm
Motor
30kw*2
37kw*2
37/45kw
37/45kw
45kw*2
45/55kw
55KW*2
Saw Blade Diameter
180MM
230mm
255mm
230mm
280mm
280mm
380mm
Spindle Diameter
70mm
70mm
70mm
80mm
80mm
80mm
100mm
Weight
2330kg
2450kg
2480kg
2550kg
2580kg
2620kg
2700kg

DS2000 Circular Blade Saw Mill Swing Blade Timber Cutting MachineDS2000 Circular Blade Saw Mill Swing Blade Timber Cutting Machine
