Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Specifications
Place of Origin :
Shandong Province, China
Brand Name :
SH
Certification :
ISO9001
Model Number :
SLS350, SLS500
MOQ :
1 SET
Price :
US $12,500 - 18,000 / Set
Packaging Details :
container loading
Delivery Time :
within 20 working days
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
1000sets/Year
Name :
Wood vertical band saw machine
Use :
Woodworking
Voltage :
380V, 50HZ, 3PH or as customer needs
Power(W) :
2*18.5KW-2*22KW
Application :
Cut four side of log,produce cants or square wood
Saw wheel diameter :
700mm
Max. Sawing Wood Diameter :
500MM
Control :
CNC digital
Feeding Speed :
Variable Frequency Speed Adjustable
Warranty :
12 months
Description

TWIN BANDSAW FOR LOG EDGES CUTTING

Designed to receive logs and make two vertical cuts removing a slab from either side of the log.

· Ideal to cut pine, eucalyptus, and teak.

· High-precision cutting.

· Laterally-supported chain.

· High-production continuous feed system.

· Produces up to 4,000 m³ per month.

· Highly efficient use of wood, with the finest cut on the market.

· Motorization and control panel included.

· Automatic feed

Technical Specifications:

Technical data SLS350 SLS500
Maximum log diameter 350mm 500mm
Minimum log diameter 100mm 100mm
Wood length 1000 to 3000mm 1000 to 3000mm
Feed speed 9-25m/min (inverter) 9-25m/min (inverter)
Conveyor length 7000mm 3500mm x 2
Band wheel diameter 700mm 760mm
Width of saw blade 50-80mm 50-100mm
Length of saw blade 4850 5200mm
Thickness of saw blade 0.9mm 0.9mm
Saw motor 2x18.5kw 2x22kw
Feed motor 5.5kw 4kw x 2
Sawn sizing control Touching screen auto setworks Touching screen auto setworks

Photos

Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw

Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw

Block Bandsaw/ Twin Vertical Band Saw (Flat bottom)
Designed to receive logs with at least one straight bottom, making two vertical cuts, removing a slab from each side of the log.

· Ideal to cut pine, eucalyptus, and teak.

· Block 100% Square

· High-production continuous feed system.

· Production up to 4,000 m³ per month.

· Highly efficient use of wood, with the thinnest kerf on the market.

· Motorization and automatic electric panel included.

· Automatic feeding, inverter speed adjustable .

Technical data :

Model SLSP400
Maximum log diameter 400mm
Minimum log diameter 100mm
Wood length 1000~3000mm
Feed speed 9~25m/min
Conveyor length 7000mm
Bandwheel diameter 700mm
Blade width 50~80mm
Saw motor 18.5KW X 2
Feed motor 5.5kw
Weight 2500kg

Deatiled Image

Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
Automatic Twin Band Saw Production Line

Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band SawTwin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw

We can also do bigger model as customer needs .

Related Saw Machine - slabs cutting saw

Specifications:

Model

Specifications

 BPJ200 BPJ250 BPJ300
Cutting width (mm) 200 250 300
Cutting height 100mm 100mm 150mm
Motor power (KW) 7.5kw x 2 7.5kw x 2 11kw x 2
Feeding Frequency variable auto feeding
Circular blade diameter 305(mm) 355(mm) 405(mm)
Weight (kg) 480 600 750
Overall size 1450x1150x1400mm 1450x1200x1400mm 1750x1250x1550mm

Photos :

Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw

Twin Heads Industrial Saw Mills, Log Processing Euipment Twin Band Saw
