MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
Specifications
Place of Origin :
shandong province
Brand Name :
SH
Certification :
ISO
Model Number :
MJ3212-Z5000,MJ3212-Z3000,MJ3210-Z5000,MJ3310-Z3000
MOQ :
1 SET
Price :
US $3,000 - 50,000 / Set
Packaging Details :
container loading
Delivery Time :
within 15 days
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
1500sets/year
Condition :
New
Type :
Vertical band saw
Usage :
Woodcutting
Voltage :
380v/3phase/50HZ or as customer needs
Warranty :
12 months
After-sale service provided :
Engineers available to service machines overseas
Description

Descriptions of vertical band saw wood machine

Vertical Band Sawmill With CNC Log Carriage

This lathe is mainly used to Vertical cut or slab-cut logs of a large or middle diameter or re-saw timbers into slabs and square logs of various specifications and it smoothly runs at a high efficiency.In combination with carriage, it will enlarge the working range and improve product quality and hence is the ideal equipment for wood working enterprises.

Applications:Processing large and middle logs and square logs together with large-or middle-size wood band saws.
Features:Automatic micro-computer control,feeding,and automatic dimensioning;high efficiency and low labor intensity;high precision,and easy operation.

Technical Parameter

 MJ3212-Z5000 MJ3212-Z3000 MJ3310-Z5000 MJ3310-Z3000

Saw Wheel Diameter (MM)

 1250 1250 1070 1000

Saw Wheel Speed RPM

 650 650 650 650

Saw Blade Length (MM)

 8600 8600 7400 7400

Saw Blade Width(MM)

 150 150 150 150

Saw Clip Movement Motor( KW)

 0.75 0.75 0.75 0.75

Saw Wheel Movement Motor( KW)

 0.75 0.75 0.75 0.75

Main Motor Power( KW)

 37 37 30 30

Carriage Clip Stake Quantity

 4 4 4 3

Carriage Wheel Quantity

 3 3 3 2

forward and backward

 Electric Electric Electric Electric

Sawing Thickness Setting

 Electric Electric Electric Electric

Max Sawing Wood Diameter(MM)

 1200 1200 1000 1000

Max Sawing Wood Length(MM)

 6000 4000 6000 4000

Track Length(MM)

 16000 12000 16000 12000

Weight (KG)

 7200 6500 4900 4200

MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting MachineMJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting MachineMJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine

Technical Parameter

 MJ328 MJ329 MJ3210 MJ3310 MJ3212

Saw Wheel Diameter

 800mm 900mm 1000mm 1070mm 1250mm

Saw Wheel Width

 110mm 120mm 120mm 120mm 140mm

Saw Wheel Speed

 750r·p·m 750r·p·m 750r·p·m 750r·p·m 750r·p·m

Saw Wheel& Clip Model

 Manual Manual Automatic Automatic Automatic

Saw Wheel Length

 5700mm 6400mm 6800mm 7400mm 8600mm

Max Sawing Wood Diameter

 650mm 750mm 900mm 1000mm 1200mm

Main Motor Power

 11kw 15kw 22kw 30kw 37kw

Weight

 1000kg 1300kg 1600kg 1800kg 3200kg

Include main motor

Include iron-made safe protective casing

Include manual lubrication

Include foundry work platform

MJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting MachineMJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting MachineMJ3310 Log Carriage Matched Vertical Band Saw Mill for Tree Logs Cutting Machine
