300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
Specifications
Place of Origin :
Shandong Province, China
Brand Name :
SH
Certification :
ISO9001
Model Number :
BPJ200, BPJ250, BPJ300, ZB250, ZB300
MOQ :
1 SET
Price :
US $4,200 - 15,000 / Set
Packaging Details :
iron frame packagings
Delivery Time :
within 15 days
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
1000sets per year
Name :
slab cutting saw
Type :
circular saw
Feeding type :
Frequency variable auto feeding
Power Type :
7.5kw x 2sets
sawing width max. :
300mm
sawing max. thickness :
100mm
Voltage :
380v OR as customer needs
Warranty :
12 months
weight :
250kgs
Guarantee :
1 year
Description

Electrical slab cutting saw cutting machine, wood slab Edges cutting machine

Wood Slabs Cutting Circular Sawmill

Specifications:

Model

Specifications

 BPJ200 BPJ250 BPJ300
Cutting width (mm) 200 250 300
Motor power (KW) 7.5kw x 2 7.5kw x 2 7.5kw x 2
Feeding Frequency variable auto feeding
Circular blade diameter (mm) 300 355 405
Weight (kg) 200 220 250

We can also do bigger model as customer needs .

Photos :

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw

Heavy Duty Wood Slabs Cutting Circular Saw

Specifications:

Model

Specifications

 ZB150 ZB250 ZB300
Cutting width (mm) 150 250 300
Cutting height 150mm 150mm 150mm
Motor power (KW) 15kw x 2 15kw x 2 15kw x 2
Feeding Frequency variable auto feeding
Circular blade diameter 305(mm) 355(mm) 455(mm)
Weight (kg) 1350 1380 1420
Overall size 4000x1200x1850mm 4000x1200x1850mm 4000x1200x1850mm

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw

Related Products:

TWIN BANDSAW FOR LOG EDGES CUTTING

Designed to receive logs and make two vertical cuts removing a slab from either side of the log.

· Ideal to cut pine, eucalyptus, and teak.

· High-precision cutting.

· Laterally-supported chain.

· High-production continuous feed system.

· Produces up to 4,000 m³ per month.

· Highly efficient use of wood, with the finest cut on the market.

· Motorization and control panel included.

· Automatic feed

Technical Specifications:

Technical data SLS350 SLS500
Maximum log diameter 350mm 500mm
Minimum log diameter 100mm 100mm
Wood length 1000 to 3000mm 1000 to 3000mm
Feed speed 9-25m/min (inverter) 9-25m/min (inverter)
Conveyor length 7000mm 3500mm x 2
Band wheel diameter 700mm 760mm
Width of saw blade 50-80mm 50-100mm
Length of saw blade 4850 5200mm
Thickness of saw blade 0.9mm 0.9mm
Saw motor 2x18.5kw 2x22kw
Feed motor 5.5kw 4kw x 2
Sawn sizing control Touching screen auto setworks Touching screen auto setworks

Photos

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw

Related Saw Machine

Block Bandsaw/ Twin Vertical Band Saw (Flat bottom)
Designed to receive logs with at least one straight bottom, making two vertical cuts, removing a slab from each side of the log.

· Ideal to cut pine, eucalyptus, and teak.

· Block 100% Square

· High-production continuous feed system.

· Production up to 4,000 m³ per month.

· Highly efficient use of wood, with the thinnest kerf on the market.

· Motorization and automatic electric panel included.

· Automatic feeding, inverter speed adjustable .

Technical data :

Model SLSP400
Maximum log diameter 400mm
Minimum log diameter 100mm
Wood length 1000~3000mm
Feed speed 9~25m/min
Conveyor length 7000mm
Bandwheel diameter 700mm
Blade width 50~80mm
Saw motor 18.5KW X 2
Feed motor 5.5kw
Weight 2500kg

Deatiled Image

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw

Complete Sawmill Production Line

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw

300mm Wood Slab Cutter Machine 7.5kw Edge Cutting Machine Circular Saw
