Specifications
Brand Name :
SH
Model Number :
SHMF1300-700, SHMF1500-800
Certification :
ISO9001
Place of Origin :
Shandong Province, China
MOQ :
1 SET
Price :
US $8,000-4,9000 / Sets
Payment Terms :
T/T, Western Union
Supply Ability :
500 sets/Year
Delivery Time :
within 20 days
Packaging Details :
container loading of wood sawdust crusher
Name :
Sawdust Wood Crusher
Feeding Inlet Size :
1300*700mm,1500*800mm
Roll diameter :
700mm, 800mm
Blade Quantity :
84pcs
Raw material :
Wood Chips Wood Pieces
Main motor power :
132kw, 160KW
Raw Wood chipper size :
2-5 cm
Operation :
Automatic distant control
Capacity :
4-8 Tons/Hour
Magnetic system :
Optional to such out iron nails, etc
Keywords :
Sawdust Wood Hammer Mill
Application :
Processing wood chips into sawdust
Description

Wood Sawdust Machine

  • Automatic operation system.
  • Optional-Sacron Cyclone Dust Collector.
  • With Bag dust collection system.
  • With Magnetic system

6mm sawdust pallet machine Wood Chipper Crusher for pellets,Wood Waste Recycling Equipment Making Sawdust Machine

Technical Data:

Model SHMF1300-700 SHMF1500-800
Feeding inlet size 1300X700mm 1500X800mm
Blade shaft diameter 700mm 800mm
Blade quantity 84pcs 84pcs
Main motor power 132kw 160kw
Production capacity 4-5ton/hour 6-8ton/hour
Feeding system 1set,5.5KW,With strong magnetic machine
Discharging system 1set
Bag dust collection 1 unit(40bags, with Supports and pipes)
Sacron Cyclone Dust Collector 1unit(1200MM dia., with Supports and pipes)
With Soft start inverter integrated control cabinet

6mm sawdust pallet machine Wood Chipper Crusher for pellets,Wood Waste Recycling Equipment Making Sawdust Machine6mm sawdust pallet machine Wood Chipper Crusher for pellets,Wood Waste Recycling Equipment Making Sawdust Machine

6mm sawdust pallet machine Wood Chipper Crusher for pellets,Wood Waste Recycling Equipment Making Sawdust Machine

Wood Crusher Machine is mainly used for building film faced plywood, wasted wood pallet, Tree bark, Slabs, off cuts, branches, straw and so on. It can work together with the baler breaker. This machine includes Host, chain plate, feeding & outlet conveyor system, intelligent electrical control. Chain Plate Feeding conveyor feeds raw materials more freely, no need changing the belt all the time. It is with reasonable structure, simple operation, high automatic level, and high safety coefficient and production capacity, less manpower, easy maintenance. It is the ideal equipment for biomass power generation enterprises.

Technical Parameter

Model SH2000-1000 SH1300-600 SH1400-600 SH1600-600
Feeding inlet size 2000x1000mm 1250x600mm 1400x600mm 1600x600mm
Blade roller diameter 1400mm 850mm 850mm 850mm
Blade roller speed 750RPM 850RPM 850RPM 850RPM
Production capacity 70-100ton/H 12-15ton/H 18-20ton/H 25-30ton/H
1 YG8 hammer blade qty 86pcs 20pcs 24pcs 28pcs
2 Blade qty 3groups/9tablets 2groups/4tablets 2groups/4tablets 2groups/4tablets
Max. Processing log diameter <800mm 450mm 450mm 450mm
Main motor power 450kw 160kw 200kw 250kw
Wood chipper size 3-5cm 2-4cm 2-4cm 2-4cm
Working life of blades 4000T-5000T 4000T-6000T 4000T-6000T 4000T-6000T

Optional :

  • Diesel engine power 400HP is workable
  • Wheels for mobile usage
  • Hydraulic collapsible outlet conveyor
  • Magnetic machine for sucking out iron products

Electrical motor type

6mm sawdust pallet machine Wood Chipper Crusher for pellets,Wood Waste Recycling Equipment Making Sawdust Machine

Diesel power type

6mm sawdust pallet machine Wood Chipper Crusher for pellets,Wood Waste Recycling Equipment Making Sawdust Machine

Wheels for mobile usage

6mm sawdust pallet machine Wood Chipper Crusher for pellets,Wood Waste Recycling Equipment Making Sawdust Machine
