Specifications
Brand Name :
SH
Model Number :
AEPN-1300
Certification :
ISO9001
Place of Origin :
Shandong Province, China
MOQ :
1 SET Wood Pallet Nailing Machine
Price :
US $4,800 - 21,500 / Set
Payment Terms :
T/T or L/C at sight, Western Union
Supply Ability :
1000sets/year
Delivery Time :
within 15 days
Packaging Details :
iron frame packings or luo packings
Name :
Wood Pallet Nailing Machine
Wood pallet length :
700-1300mm
Wood pallet width :
800-1300mm
Working mode :
Automatic feeding and stacking
Voltage and power :
220V/ 2kw Servo motor
Number of Coil Nail Guns :
3pcs or 4pcs
Air pressure :
0.8MPA
Nail gun speed :
7times/second
Production capacity :
1- 2tray/minute
Weight :
2000kg
Description

Machine to make wood pallets, Automatic Wood Pallet Nailing Machine for Euro trays

Professional Wood Pallet Making Machine / Machine To Make Wood Pallet

Euro Pallet Automatic Wood Pallet Making Line

1. Euro Wood Pallet Pier Automatic Connecting Nailing Machine

Model SLDJ-1300-3
Block width 60-150mm
Board Length 600-1300mm
Nail gun CN70*3Stanley BOSTITCH Stitch CN70*3
Nailing method 1 nail, 2 nails, 3 nails, 4 nails, 5 nails
Air pressure 0.8MPA
Nail gun speed 4-8 s/time
Motor power 1.5KW Servomotor
Voltage 220V(Customized)
Operating mode Touch screen
Production mode Manual discharge/automatic pin pier

Professional Wood Pallet Making Machine / Machine To Make Wood Pallet

2,Automatic European pallet nailing machine

Model AEPN-1300
Wood pallet length 700-1300mm
Wood pallet width 800-1300mm
Working mode Automatic feeding and stacking
Operation mode Touch screen
Operational mode Pneumatic operation
Voltage and power 2kw Servo motor
Air pressure 0.8MPA
Nail gun speed 7 times /second.
Production effciency 1-2pcs /min
Number of nail guns 6P CN70,CN58
Weight 2000kg

Professional Wood Pallet Making Machine / Machine To Make Wood Pallet

3.Wood pallet branding machine

Model LY-4
Processing Size 800-1300mm
Branding material Copper/die steel
Air pressure 0.8MPA
Branding speed 4-8 s/time with pallet machine speed
Motor power 0.75KW*2
Number of branding 1-6 pcs
Control mod Pallet machine production line integrated supporting

Professional Wood Pallet Making Machine / Machine To Make Wood Pallet

4. Pallet angle cutting machine

Model PQ1300-4
Processing size 800-1300mm
Circular saw blade diameter 300mm
Motor power 2.2KW*4
Working mode Automatic feed,Automatic Angle cutting
Weight 350kg

Professional Wood Pallet Making Machine / Machine To Make Wood Pallet

5. Wooden pallet palletizer

Model MD-1300Z
Processing size 800-1300mm
Lift control Hydraulic
Palletizing speed 4-8 s/time
Model power 5.2KW

Professional Wood Pallet Making Machine / Machine To Make Wood Pallet

Related Products

Pallet Notcher

Model WPN-1 WPN-2
Power 15kw 30kw
Material of knife Alloy Alloy
Capacity 600-800pics/h 1800pics/h
Processing size Wood pallet length: max 1800mm Wood pallet length: max 1400mm
Wood pallet width: 160mm Wood pallet width: max 90mm
Wood pallet thickness:40-60mm Wood pallet thickness: 40-60mm
Slot depth: <45mm Slot depth: <45mm
Slot width: 200-230mm Slot width: 200-230mm
Machine size 1200*1100*1200mm 2300*1300*1300mm
Machine wight 400kg 1000kg
Feature Slot smooth, size consistent
Apply for many kinds of slots, also can customized.
