Specifications
Brand Name :
SH
Model Number :
MB26, MB36, MB700, MB1000, MB1300
Certification :
ISO9001
Place of Origin :
Shandong Province, China
MOQ :
1 SET wood planer
Price :
US $2,200 - 5,299 / Set
Payment Terms :
T/T, Western Union
Supply Ability :
1500sets/year of Wood planer
Delivery Time :
within 20 days
Packaging Details :
container loading
Product name :
wood planer
Condition :
New
Power(w) :
3kw
Max. planning width :
1300mm
Max. planning thickness :
10-200mm
Max. planning length :
4500mm
Planing head diameter :
100mm
Polishing head diameter :
125mm
Application wood :
for log timber production
After-sales service provided :
Online support,commissioning and training
Keyword :
planer
Warranty :
1 Year
Voltage :
380V,or as customer needs
Application :
Woodworking
Color :
as your required
Weight :
180 to 260kgs
Description

MB1300 Wood Planer slab flattening machine matched with the portable sawmill

Wood Planer

Expand your business with the MB Series planer and begin the production of planed timber products.

  • It planes rough wood surfaces smooth.
  • The MB Series Planer uses the same log bed as the Portable Horizontal Band Sawmill, and they can be used together or separately.
  • The PLANER head can be added to an existing PORTABLE sawmill and logs can be processed into a finished product without ever leaving the sawmill bed.
  • After the log has been squared with the sawmill, the MB Series Planer can then mould or plane it into the final product.

SPECIFICATIONS:

Model MB26 MB36 MB700 MB1000 MB1300
Max. Planning width 650mm 900mm 700mm 1000mm 1300mm
Max. Planning length 3000mm 3000mm 4500mm 4500mm 4500mm
Processing thickness 10-200MM 10-200MM 10-200MM 10-200MM 10-200MM
Main motor power 3kw 3kw 3kw 3kw 3kw
Planing head diameter 100mm 100mm 100mm 100mm 100mm
Polishing head diameter 125mm 125mm 125mm 125mm 125mm
Dust hole 100mm 100mm 100mm 100mm 100mm
Weight 180kg 200kg 180kg 230kg 260kg
Matched sawmill model SW26 SW36 MJ700 MJ1000 MJ1300

Large Plank polishing machine(MB1700)

Specification:

Max processing planks width 1700mm
Max processing planks length 3500mm
Max processing planks thickness 10-200mm
Main motor power 3kw
Planing head diameter 100mm
Polishing head diameter 125mm
Weight 560kg

FlFlattening And Sanding Redwood Slab With Sawmill Flattening Machine, Portable Sanding MachineFlFlattening And Sanding Redwood Slab With Sawmill Flattening Machine, Portable Sanding Machine

FlFlattening And Sanding Redwood Slab With Sawmill Flattening Machine, Portable Sanding MachineFlFlattening And Sanding Redwood Slab With Sawmill Flattening Machine, Portable Sanding Machine

Portable Horizontal Band Sawmill (Electric Model )

  • Portable horizontal band saw which is easy to install and operate.
  • Finished with Carbide band saw blade for hard wood cutting .
  • The sawing kerf is small, reduce the waste to high output.
  • The computerized sawmill is sutiable for cutting expensive wood in the furniture factory and move around to cut wood in virgin forest .
Specifications:

Model

MJ700E MJ1000E MJ1300E MJ1600E

Max. Sawing Wood Diameter

 700MM 1000MM 1300MM 1600MM

Saw Wheel Diameter

 600MM 700MM 700MM 700MM

Sawn Thickness

 2-250MM 2-300MM 2-300MM 2-300MM

Sawing Wood Length MM

 1300-4500 1300-4500 1300-4500 1300-4500

Main Motor Power

 15KW 18.5KW 22KW 30KW

Lifting Motor Power

 1.5KW 1.5KW 1.5KW 1.5KW

Total Weight (KG)

 1100 1100 1300 1500

Detailed Images of stanard model:

FlFlattening And Sanding Redwood Slab With Sawmill Flattening Machine, Portable Sanding Machine
