High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
Specifications
Brand Name :
SH
Model Number :
SHBP6000, SHBP9000,etc
Certification :
ISO9001
Place of Origin :
shandong province
MOQ :
1 SET
Price :
US $4,800 - 15,000 / Set
Payment Terms :
T/T or L/C at sight
Supply Ability :
200 Set/Sets per Month
Delivery Time :
within 15 days
Packaging Details :
luo packings
Condition :
New
Spindle Speed :
1500
Wood Diameter Range :
5cm-35cm
Peeling Rate :
99.9%
Wood Loss Rate :
0.5%
Wood Length Range :
12000mm
Dimension(L*W*H) :
9000*1500*1700mm
Weight :
5000KG
After-sales Service Provided: :
Engineers available to service machine overseas
Description

Wood Tree Debarking Peeling Log Debark Remove Bark Machine,Wood Debarkers

Single Roll Log Debarker

Introduction:

  • The log debarker machine is used to take off the skins of round logs .
  • Processing log max. diameter : 320mm
  • Processing log max. length: 9meters
  • Peeling rate:98%

Specification:

Model SHBP6000 SHBP9000
Capacity Ton/Hour 5-10 10-15
Motor Power 37KW 45KW
Log Diameter 15-320mm 15-320mm
Debarking Rate 98% 98%
Max Log Length 6000mm 9000mm
Weight 4000kg 5000kgs

High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine

Double Rolls Log Debarker

Model SHBPD4500 SHBPD6000 SHBPD9000
Capacity TON/HOUR 3-6 5-10 10-15
Motor Power 7.5kw*2 11*2 15*2
Log Diameter 50-250mm 50-250mm 50-250mm
Debarking Rate 98% 98% 98%
Max Log Length 4500mm 6000mm 9000mm
Overall Size 5.8*1.6*2m 7.5*1.6*2m 11*1.6*2m
Weight 4500kgs 5200kgs 6500kgs

High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling MachineHigh Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine

Related Products

Wood Shaving Machine

Technical Specifications:

Model SHBH500-2 SHBH500-4 SHBH500-6
Processing wood max. length(mm) 800 1400 1400
Processing max. width/diameter(mm) 500 500 500
Shaft quantity 2 4 6
Blade (pcs) 8 16 24
Motor speed (rpm) 3500 3500 3500
Bin length (mm) 800 1400 1400
Total Motor power (kw) 10.5KW 23.25KW 30.75KW
Shaving depth (mm) 0.2-1 0.2-1 0.2-1
Shavings output 500KG/H 1000KG/H 1500KG/H
Machine weight 950kgs 1800kgs 2200kgs

1,With one set of blades includes;

2, with pneumatic capping included, which can improve working capacity;

Detailed Images:

High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine

High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine

High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling MachineHigh Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine

Wood Wool Machine

Technical Data

Model

 SHMS500-1 SHMS500-2

Processing Log Length
 300-500mm 300-500mm
Max Processing Log Diameter
 160mm 160mm x 2pcs

Blade Quantity
 2 2
Excelsior Width
 1mm-10mm 1mm-10mm

Excelsior Thickness
 0.1mm-1mm 0.1mm-1mm
Excelsior Length
 300-500mm 300-500mm
Total Motor Power
 9kw 16.5KW
Production Capacity
 50-100kg/hour 100-150KG/Hour

Detailed Image

Model SHMS500-2

High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine

High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine

Wood Chipper

High Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling MachineHigh Efficiency Log Peeler Tree DeBarking Machine Wood Log Debarker Peeling Machine
