Specifications
Brand Name :
Texas Instruments
Model Number :
TS5A3166QDCKRQ1
Certification :
/
Place of Origin :
N/S
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
9999999+PCS
Delivery Time :
2-7 work days
Type :
EMI Filter
Package type :
Throught Hole
Nominal center frequency :
10KHZ~30MHZ
Transfer function :
Band Pass
Insertion loss :
60dB-90dB
Description

EMI Filter IC Texas Instruments/TI TS5A3166QDCKRQ1

ECAD Module PCB Symbol,Footprint & 3D Model
Supply and Demand Status Balance
Popularity High
Fake Threat In the Open Market 59 pct.
Quantity per package 3000
HTSUS 8542.39.0001
ECCN EAR99
REACH Status REACH Unaffected
MSL Level 1 (Unlimited)
Family Name TS5A3166
Package 5-TSSOP, SC-70-5, SOT-353
Mounting Surface Mount
Operating Temperature Range -40°C ~ 125°C (TA)
Package Reel - TR
Series Automotive, AEC-Q100
Manufacturer Texas Instruments
Estimated Pruduction Lead Time 34 Weeks
Categories Integrated Circuits (ICs)
Case / Package SC-70-5

Features for the TS5A3166-Q1

  • Qualified for Automotive Applications
  • Isolation in Powered-Off Mode, V+ = 0
  • Low ON-State Resistance (0.9 Ω)
  • Control Inputs are 5.5 V Tolerant
  • Low Charge Injection
  • Low Total Harmonic Distortion (THD)
  • 1.65-V to 5.5-V Single-Supply Operation
  • Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II
  • ESD Performance Tested Per JESD 22
    • 2000-V Human-Body Model (A114-B, Class II)
    • 1000-V Charged-Device Model (C101)

Description for the TS5A3166-Q1

The TS5A3166-Q1 is a single-pole single-throw (SPST) analog switch that is designed to operate from 1.65 V to 5.5 V. The device offers a low ON-state resistance. The device has excellent total harmonic distortion (THD) performance and consumes very low power. These features make this device suitable for portable audio applications.
