Features for the SN74AXC4T245-Q1

• AEC-Q100 qualified for automotive applications
• Available in wettable flank QFN (WBQB) package
• Fully-configurable dual-rail design allows each port to operate with a power supply range from 0.65 V to 3.6 V
• Operating temperature from –40°C to +125°C
• Multiple direction control pins to allow simultaneous up and down translation
• Glitch-free power supply sequencing
• Up to 380 Mbps support when translating from 1.8 V to 3.3 V
• VCC isolation feature:
  • If either VCC input is below 100 mV, all I/O outputs are disabled and become high impedance
• Ioff supports partial-power-down mode operation
• Compatible with AVC-family level shifters
• Latch-up performance exceeds 100 mA per JESD 78, class II
• ESD protection exceeds JEDEC JS-001
  • 8000-V human-body model
  • 1000-V charged-device model

Description for the SN74AXC4T245-Q1

The SN74AXC4T245-Q1 AEC-Q100 qualified device is a four-bit non-inverting bus transceiver that uses two individually configurable power-supply rails. The device is operational with both VCCA and VCCB supplies as low as 0.65 V. The A port is designed to track VCCA, which accepts any supply voltage from 0.65 V to 3.6 V. The B port is designed to track VCCB, which also accepts any supply voltage from 0.65 V to 3.6 V. Additionally the SN74AXC4T245-Q1 is compatible with a single-supply system.

The SN74AXC4T245-Q1 device is designed for asynchronous communication between data buses. The device transmits data from the A bus to the B bus or from the B bus to the A bus, depending on the logic level of the direction-control inputs (1DIR and 2DIR). The output-enable inputs (1 OE and 2 OE) are used to disable the outputs so the buses are effectively isolated. The SN74AXC4T245-Q1 device is designed so the control pins (xDIR and x OE) are referenced to VCCA.

To ensure the high-impedance state of the level shifter I/Os during power up or power down, the xOE pins should be tied to VCCA through a pull-up resistor.

This device is fully specified for partial-power-down applications using the Ioff current. The Ioffprotection circuitry ensures that no excessive current is drawn from or to an input, output, or combined I/O that is biased to a specific voltage while the device is powered down.

The VCC isolation feature ensures that if either VCCA or VCCB is less than 100 mV, both I/O ports enter a high-impedance state by disabling their outputs.

Glitch-Free power supply sequencing allows either supply rail to be powered on or off in any order while providing robust power sequencing performance.
