Specifications
Type :
Wrapping Machine
Applicable Industries :
Manufacturing Plant
After Warranty Service :
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location :
None
Showroom Location :
None
Condition :
New
Application :
Food, chocolate
Packaging Type :
Film, Foil
Packaging Material :
Paper
Automatic Grade :
Semi-automatic
Driven Type :
Electric
Voltage :
220V 50/60Hz
Place of Origin :
Sichuan, China
Brand Name :
Shengli
Dimension(L*W*H) :
2670*1520*2350mm
Weight :
3000 KG
Certification :
CE
After-sales Service Provided :
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service
Warranty :
1 Year
Key Selling Points :
High-accuracy
Marketing Type :
New Product 2021
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
PLC, Pressure vessel, Gear, Motor, Engine, Bearing
Chocolate Size :
L:80-183 W:40-82 H:10-40 (mm)
Packing Speed :
60-100pics/min (According to the size)
Total Power :
15.0KW
Power Supply :
380V 50HZ 3PH (Can be customized)
Air Supply :
Pressure: 0.6MPa Flow: 0.6 M³/Min
Wrapper Material :
Foil,Wax paper,BOPP.etc.(Must be easy to fold)
Wrapper Width :
Inner Max.225mm, Outer Max.250mm
Wrapper Roller Size :
Inner Dia:76-90mm,Outer Dia≤300mm
Melting Gum Device :
Robatech(Switzerland)
Gross Weight :
3000KGS
Packaging Details :
Wooden case package as an international trade package.
Port :
ShangHai / Shenzhen / Guangzhou
Supply Ability :
10 Set/Sets per Month
Price :
$125,000.00/sets 1-2 sets
MOQ :
1pc
Description
Product Overview

SL-SBZB100D Chocolate Tablet/Bar Fold Wrapping Machine

This series of packaging machines is specially designed for large size chocolate tablets, it is compatible with multiple size chocolate bar packing. It is also possible to achieve both heat sealing with aluminium foil on the inside and sealing with spray glue on the outside. The machine can also be interfaced with a chocolate forming machine to form a complete production and packaging line, saving costs and increasing efficiency for the factory.
FEATURES AT A GLANCE


Multi-functional
Efficient
Easy to operate
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Sample
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Sample
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Sample
PRODUCT CONFIGURATION
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Touch Screen
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Folder
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Details
SALES AND SERVICE NETWORK
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Successful Project
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Project in Thailand
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Project in India
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
Project in Russia
SIMILAR PRODUCTS
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
220V 50/60Hz Chocolate Tablet/Bar Fold Packing Machine for Local Service Location
FAQ
Q1: Is engineer available to serve oversea? Yes, but the travel fee is responsible by you. In order to save your cost, we will send you a video of full details machine installation and assist you till the end. Q2. How can we make sure about the machine quality after packing the order? Before delivery, we will send you the pictures and videos for you to check the machine quality. And also you can arrange for quality checking by yourself or by your contacts in China. .Testing & detecting the machine before shipping.
