Full Automatic Candy/Chocolate Top-twisting Packing Machine Technical

Product Description:

1.Main Instruction

This complete machine is a full automatic high-speed packing machine,which using automatic control to feed and pack foods,such as chocolate and other food which are not easily be handled or fragile.

The complete machine consists of 1 unit SL-SBDN260 Top-twisting Packing Machine and 1 unit SL-SBZL400 Arranging and Feeding Machine.

Special Features:

1.Adopt PLC & program software , easy operating and setting .Auto-human touch screen and three color warning light ,self failure diagnosis , clear failure display .

2.Fully automatic program-controlled with servo motors,highly stable and reliable

3.Flexible in color sensor settings,paper feeding self-tracking and correction during packing ,providing a consistent packing style and a good product appearance.

4.Self-protection for abnormal product.

5.Online product feeding status monitoring-only feeding wrapping paper when product arrives desired position,which keeps paper consumption at an extremely low level.

6.Removable truckle with machine ,height can be adjusted.

2.Packing Machine Technical Specification and Main Components

(1).Main Specification and Technical Parameters

Table 1

Table 2

Table 3

Table 4

Table 5

(2).Main Components

l Servo motor for feeding paper Japanese(Panasonic )

l Touch screen Taiwan(Weinview)7.5”

l Frequency converter Taiwan(Delta)

l Candy sensor Germany(LEUZE)

l Color code sensor Germany(SICK)

l Over size candy proximity switch Germany(LEUZE)

l Origin proximity switch Germany(LEUZE)

l Encoder Italian(LIKA)

l Solid relay Japanese(Omron)

l Switch power supply China

l Precision potentiometer Moxie(Duoquan)

l PLC Chengdu(SL)

3.Arranging and Feeding Machine Technical Specification and Main Components

5.Package and Shipping

(1)Package Standard:Wooden case package as international trade package.

(2)Package Supply and Recovery:Supplier supply package according to customer requirements and recovery depend on customer.

(3)Package Size and Weight(just for reference )

(4)Send to customer’s named place in China

6.Other Terms

6.1.The Condition and Limits supplier charge:Guarantee one year in standard operation

6.2.Acceptance Inspection and Means:According to enterprise standard in supplier factory,if you have any suggestion please tell us in one mouth after debug

6.3.Spare Parts and Tools Instruction:Check in Appendix 1

6.4.Spare Parts Guarantee: one year ,except spare parts loss because of incorrect operation.

6.5.Other Terms:Facility’s installation and debugging should be finished in BUYER’s factory by the assigned engineer (usually ONE person) from SELLER’s factory.BUYER shouldafford all the expenses generated as soon as engineer being away from China,which including transportation,meals,

accommodations,as well as additional cost during installation and debugging.
