Intermediate Speed Fibre Cigarette Filter Machine Easy Operation 250m/min ZL23
Intermediate Speed Fibre Cigarette Filter Machine Easy Operation 250m/min ZL23
Specifications
Brand Name :
Upperbond
Place of Origin :
China
MOQ :
1 Set
Payment Terms :
T/T, L/C
Supply Ability :
200 sets per year
Delivery Time :
30Works Dates
Packaging Details :
Wooden Case
Model Number :
ZL23
Certification :
CE
Price :
Negotiation
Color :
White
Capacity :
250m/min
Brand :
Upperbond
Diameter :
7.7mm
Length of filter rod :
80-144mm±0.5
Unit weight: :
3500Kg
Description

Intermediate Speed Fibre Cigarette Filter Machine Easy Operation 250m/min ZL23

ZL23 set of fiber filter rod forming machine consists of YL13 loose gluing machine andYL23 filter rod forming machine. It takes cellulose acetate tows or polypropylene tows as raw material, after air loosing,thread loosing,gluing,involution,sideseal,forming and cutting, formed equilong filter tipping rod which meet the high-speed adapter request.

The machine can also use acetate tow and C tow. Opium pipe uses unitary and hot melt adhesive side sealing, making it easy for adjustment and operation, and reliable for splicing.The rod cutting blade applied with automatically cut feeding and automatically sharpen makes the filter rod notch smooth and flattening.

Opener applied with three-level air opening,two-level thread roller opening to completely stretch,loose,spread and gluing uniformity, and the forming machine take high-precision spiral bevel gear and paralleling short shaft driving, single tool rod cutting, to make sure small error of filter rod length.

Parameters:

Technical parameter

Product capability

250m/min(vinegar fiber) 160m/min(C fiber)

Length of filter rod :

80-144mm±0.5

Circle of filter rod:

24.0～24.5mm±0.20

Devilation from circular form:

≤0.35mm

Unit power:

22KW

Compressedair:

flow≥1.5m3/min, Kpa≥0.5MPa

Unit weight:

3500Kg
