Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
Specifications
Brand Name :
GET
Model Number :
Water Sprayer Truck
Certification :
ISO 9001/TS16949
Place of Origin :
China
MOQ :
2 units
Payment Terms :
T/T, L/C
Supply Ability :
10 units per month
Delivery Time :
45 working days
Packaging Details :
packed in nude
Material :
Carbon Steel Q345/Q235
Tanker Volume :
22,000L
Axle No. :
3
Transport Liqulid :
Water
Color :
Customized
Tanker Shape :
Square-Round
Description

6×4 Water Sprayer tank truck with volume of 22000L for city Road cleaning and Dustfall

6×4 Water Sprayer tank truck with volume of 22000L for city Road cleaning and Dustfall
6×4 Water Sprayer tank truck, HOWO76 cabin,(air-condition, one bed); with WD615.69Sinotruk engine,336HP, with HW19710 transmission, with ZF steering(RHD/LHD), with12R22.5tires, etc.
SPECIFICATION 　 HOWOZZ1257M4641W
Dimension(L×W ×H)(unloaded) 10300×2496×3258
Tank capacity (m3) 22
Approaching angle/Departure angle(°) 19/26
Overhang(front/rear) (mm) 1500/1670
Wheel base (mm) 3625+1350
Max speed(km/h) 75
Curb weight(kg) 12000
Loading Weight(kg) 18000
Engine

(Steyr technology, made in China)		 Model WD615.87,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection
Fuel type Diesel
Power, max(kw/rpm) 247/2200(336HP)
Emission EURO 2
Fuel tanker capacity 300
Transmission Model HW19710,10 forward&2 reverse
Brake system Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels
Steering system Model ZF8098 (RHD/LHD)
Front axle Steering with double T-cross section beam HF7
Rear axle Pressed axle housing, central double reduction with differential locks between axles and wheels
Tyre 12R22.5
Electrical system Battery 2X12V/165Ah
Alternator 28V-1500kw
Starter 7.5Kw/24V
Cab HOWO76 Standard cab, all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
Steel Structure:
Material:High strength low alloy steel with 350 MPa yield strength is used for welded I-beam and 235 MPa in other fabricated parts.
Water Sprayer Water Pump
Sprayer 2 sets at the front
water monitor at the tail of the truck

Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning

Multifunctional 6×4 Water Sprayer Tanker Truck 22000L Capacity For Sidewalk Cleaning
