3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
Specifications
Model NO. :
9613GYQ
Code & Material :
"Q420r for Shell Q345r for Head"
Design Pressure :
1.61MPa
Transport Package :
Bare Package
Specification :
61000L
Trademark :
GET ENERGY GET VEHICLES
Origin :
China
Supply Ability :
100 Unit/Units Per Month
Customization :
Available
Tanker Material :
Carbon Steel Q380r
Capacity :
61900L
Description

61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer with 3 axles for LPG

Liquefied petroleum gas or liquid petroleum gas (LPG or LP gas), also referred to as simply propane or butane, are flammable mixtures of hydrocarbon gases used as fuel in heating appliances, cooking equipment, and vehicles.

As it burns release less CO2 per unit of energy than does coal or oil, but a higher calorific value (94 MJ/m3 equivalent to 26.1kWh/m3) than natural gas (methane) (38 MJ/m3 equivalent to 10.6 kWh/m3), so it become popular as a Clean energy in these years.

G.E.T Vehicles provides light weight and high-volume Medium-pressure Gas
(LPG) tank semi-trailer with 3 axles and more to customers. With 61900-liter max volume, 30,000 filling weight, European ADR standard and ASME STANDARD, it is an optimal transporter for ENERGY logistic industry.

Series of products: vehicles for transportation of LPG, propane, propylene, liquid ammonia, etc.3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer with 3 axles for LPG
Model 9613GYQ Capacity 61.9m³
Truck To be provided by the end user QTY AS LISTED ABOVE
Design pressure 1.61MPa MAWP
Code & Material Q420R for shell
Q345R for head		 Heads Double Spherical Heads
Height from the 5th wheel top surface to the ground (when the truck is at empty):To be provided by the end user mm
Nitrogen replacement is required.
Tank Pressure relief valve As above 2 pcs
Level gauge As above On the side of the tank
Drain No
Manway DN450
Steel baffle Steel
Filling & Discharge System Control method Mechanical
Liquid discharge Single liquid discharge system Side of the trailer
Valve box Double valve boxes Side of the trailer
Other Fittings Tool box Double tool boxes Side of the trailer
Mudguard Steel mudguard
Ladder No
Level gauge armrest No
Water tank or hose box NO
Fire extinguisher 2 × 8kg
King pin JOST 2' king pin
Landing gears JOST separate winding, A400
model A400
Running Gear Slanted or horizontal
Suspension Chinese Spring suspension 4pcs
Spare wheel carrier Single
ABS KORMEE brand 4S/2M
Rim Steel rim 9×22.5
Axle BPW brand 3 PCS 12Ts capacity
Tire brand Double coin 13 PCS (Including one spare tire)
Tire dimension 12R22.5 Tubeless
Light LED lamps; 24V voltage.
Side protection Steel
Parking brake Pneumatically operated
Earthing Electrostatic strip
Surface Reflective stickers 3M reflective stickers
Painting & logo TO BE CONFIRMED IN THE CONTRACT
Special Requirement TO BE CONFIRMED IN THE CONTRACT
Stability System
The stability system of GET Vehicles acts as real-time monitoring of driving conditions of the vehicle and intervenes automatically in situations where vehicle stability enters a critical area. Its brakes specific wheels in order to help the vehicle returning to safe driving conditions, preventing rollover or out of control.
 3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
Operation Monitoring System
Operation-monitoring system detects the whole process about tank loading, transportation and tank unloading. All the PRV Valve , Emergency valve ( liquid Phase and Gas Phase) ,vent valves, gas adaptor , Thermometer and the ball valves are mostly imported from America Fisher or Rego
 3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
Lift-up Axle System
Lift-up Axle System can increase driving distance and reduce costs of tires significantly. Test results indicate that the total distance of tires mounted on this system can be up to 750000 km, twice or more than traditional system.
 3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
Air Suspension
Comparing to traditional leaf spring suspension, air suspension can adjust the extent of soft or firm and the height of the vehicle, provide enhanced performance of shock-absorbing and driving safety.
 3 Axles 61000L Liquefied Petroleum Gas Lorry Tanker Semi Trailer For LPG
