Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Specifications
Use :
Truck Trailer
Type :
Semi-Trailer
Material :
Steel
Size :
13000
Max Payload :
30400 L
Place of Origin :
China
Brand Name :
GET ENERGY | GET VEHICLES
Tank Series :
2 Axles Carbon Steel Tank Semi-Trailer
Tanker Volume :
30400L
Tanker Application :
Fuel , Oil , Diesel, JET, Gasoline, Water,Bitumen
Truck Trailer Axle :
Square Drum Axle brand FUWA / BPW
Trailer Suspension :
Mechanical Tandem / Air Spring / Bogie
Trailer Brake System :
Dual air brake system, WABCO/HALDEX relay valve, OPTIONS: ABS/EBS
Tank Discharge system :
Pneumatic Bottom API Adaptor Loading Valve system
Tanker Valves :
Emergency shut foot valve ,
Trailer Surface :
Clean SA-2.5 Grade with marine paint of not less than 80μm
Usage :
Urban close distance transportation
Packaging Details :
A. CBU type can ship with Rol-Rol and General Cargo Vessels and The flatbed Container .
B.CKD& SKD Type can ship with Container
Port :
QINGDAO,CHINA
Supply Ability :
100 Unit/Units per Month
Price :
$14,600.00 - $18,406.00/units
Description
Product Overview

What is a Tank Truck

A tank truck or tanker truck (United States usage) or tanker (United Kingdom usage), is a motor vehicle designed to carry
liquefied loads, dry bulk cargo or gases on roads. The largest such vehicles are similar to railroad tank cars which are also
designed to carry liquefied loads. Many variants exist due to the wide variety of liquids that can be transported. Tank trucks tend to be large; they may be insulated or non-insulated; pressurized or non-pressurized; and designed for single ormultiple loads (often by means of internal divisions in their tank). Some are semi-trailer trucks. They are difficult to drive due to their high center of gravity.

Why Choose Our Carbon Steel with 2 axles

Carbon Steel is the favorite material of Chinese Tank-manufacturing all the time because of not only its high material strength, but also the characters of easy-repair and low maintenance costs. We provides high-volume and small-size carbon steel fuel Tank semi-trailer with 2 axles to customers. With 36000-liter max volume, 8000kg min weight and European ADR standard, it is an optimal transporter for fuel logistic industry.
Tank series, Liquid foods, Water, Fuel, LPG, CNG, CO2, grain, powder cement, chemical liquids etc. Tank Size: Round Shape, Square Round shap,Ellipse Shap etc. Able to be transportation in container at CKD and SKD type, and we supply the technology support for assembling. Effective volume: 3000L----80000L
FEATURES AT A GLANCE
1. Low Investment
2. High Steel Material
3. Easy & Quick Repair
4. Low maintenance costs

Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Front elevation
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Valves Box elevation
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Tail elevation
PRODUCT SPECIFICATIONS
30400L 23T Capacity Carbon Steel Fuel and Refuel Tank Semi Trailer with 2 axles for Fuel and Diesel transit in Downtown
Items
GET9302GYY.Ecomic
GET9303GYY.Plus
GET9304GYY.Plus+
GET9305GYY.Delux
Overall Exterior dimension（mm）
Length
13000
Width
2500
Height (unload)
3200
Exterior dimension of Tank body（mm）
12730
Tank Capacity（L）
30400
GVW（kg）
31500
Dead weight（kg）
8500
Rated payload（kg）
23000
Wheel base（mm）
8170+1310
Tread（mm）
Tread at front
Tread at rear
1830
Front/Rear Overhang（mm）
/2300
Approach/Departure angle（°）
/19,17
Rated payload of 5th wheel
10010
Trailer Running System
Trailer Axle
GET SQUARE AXLE 12T*2
BPW 12T*2
GET SQUARE AXLE12T*2
BPW 12T*2
Tires
11R22.5
11R22.5
11R22.5
11R22.5
Suspension
Tandem Steel Leaf Spring Mechinical Suspension
Air Bag Spring Suspension
Brake System
Dual air brake system, Wabco relay emergency valve with ABS OPTIONS: EBS
Kingpin:
3.5” /2” JOST.
Landing Gear:
2 speed road side winding with sand shoe,Type: JOST C200T.
Electrical System:
Complete 24V installation with modular wiring harness. 7 pole plug placed at front in accordance to ISO, norms NO.1185.
OPTIONS :
1. FUEL/WATER PUMP FOR PRIME TRACTOR
2. INSULATED COVER TO BE AN INSULATED Tank
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Tank Safety Valves
1. Manhole Cover
Aluminum Material Size : φ460, 560,580 witih P/V vent Valves and Safety Valves
2. Emergency Foot Valves
Aluminum Alloy Material size : 2" (80) , 3" (100) ,Pneumatic Control
4. API Adaptor Valves
Aluminum Alloy Material size : 3' (100) API Adaptor Valves
6.Vent Recovry System:
Aluminum Material : Vapor Vent Valve,Combing Vent Valve,Vapor Adaptor Valve,Vapor Recovery Joint
3. Pneumatic Control System
Others:
Spare Tire Carrier: Equipped two sets per chassis without spare tire.
Side Guard: Steel.
Tool Box: Equipped one set.
Painting: Color by customer’s requirement.
Marking: By customer’s requirement.
Options: Oil Tank: 300L carbon steel.
PRODUCT CONFIGURATION
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles

Closed Loading System

There are many significant advantages offered by Closed Loading System, such as fire prevention, spill prevention, higher operation safety, vapor recovery, avoidance of product contamination, faster loading and less expensive loading islands. It has
become a standard required by the government.
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles

Stability System

The stability system of GET Vehicles acts as real-time monitoring of driving conditions of the vehicle and intervenes
automatically in situations where vehicle stability enters a critical area. Its brakes specific wheels in order to help the vehicle returning to safe driving conditions, preventing rollover or out of control.
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles

Operation Monitoring System

Operation-monitoring system detects the whole process about tank loading, transportation and tank unloading. All real-time information about manholes, cut off valves, API connections, pipes and bottom valves will be detected and saved.
SALES AND SERVICE NETWORK
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Successful Project
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Project in SouthEast Asia
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Project In Latin America
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
Project in Africa
Related Products
Clean SA-2.5 Grade Surface 30400L 23T Capacity Fuel and Refuel Tank Semi Trailer with 2 Axles
FAQ
Q1：Why choose carbon steel tank semi-trailer?
A1：Carbon Steel is the favorite material of Chinese tanker-manufacturing all the time because of not only its high material strength, but also the characters of easy-repair and low maintenance costs. G.E.T Vehicles provides high-volume and small-size carbon steel fuel tank semi-trailer with 3 axles to customers. With 50000-liter max volume, 9200kg min weight and European ADR standard, it is an optimal transporter for fuel logistic industry.
Q2：what is necessary for a Tank Semi trailer Inquiry ?
A2：a. The Volume of the Tank of your demands b. The Material of the tank you want ? C. The loading Liquid Medium for the tank ? For Example: 2 units Carbon Steel 42000L for Fuel with 4 compartments.
Q3：How to ship the tank Semi trailers ?
A3：We can supply the tank in two types, one is CBU ( complete Built up ) the other is SKD ( Semi -Knocked Down )and CKD ( complete Knocked Down). a. CBU type can ship with Rol-Rol and General Cargo Vessels and The flatbed Container . b.CKD& SKD Type can ship with Container to save the Freight, and we can aslo supply the assembly Technology.
