Specifications
Place of Origin :
China
Brand Name :
GET Camping | GET VEHICLES
Type :
other parts
Material :
FRP Composite Sandwich panels 30-100mm
Design Code :
Square Base Camper Shell
Width :
2200mm for Container Shipment
Height :
2200mm
Side Wall Thickness :
50mm , Opinion: 30~80mm
Floor Thickness :
80mm,Opinion: 60~120mm
Composite Material :
FRP : Glassfibre Reinforced Polyester.1.5~2.5mm
Thermo Material :
XPS / PIR 40-45kg/cbm
Embedded Frame :
Side Awing Fame, Roof Rail ,Rear Spare Tire Frame
Working Experience :
35 years for Composite Materials
Application :
RV, Motorhomes, Caravan Trailers
Price :
$11,500.00 - $16,800.00/units
Description
Product Overview

Rectangle Box -Base Box

GET Industry Rectangle Box provides an excellent platform for an expedition vehicle. Wh for a compact RV, a pick-up , a camping or an off-road expedition vehicle. 1. We supply the Rectangle Box up to a cabin length of 14.8 m ( Caravan Trailers) , in a variety of wall thicknesses (from 30mm to 125mm) and FRP or Steel ( Aluminum, PPGL) surfaces. 2. The Rectangle Box is offered as an FRP or aluminum composite box and is available either fully assembled or as a self-build kit ( Flat-packed). 3. A steel frame and/or empty pipes and cable ducts can be integrated into the walls and floor during the vacuum pressing process. 4. An optional double floor for installing water tanks, batteries, and different floor heating solutions is available. This will optimize weight distribution and improve frost resistance. 5. A full range of doors, windows, hatches and skylights is available at prices tailored to your requirements.
FEATURES AT A GLANCE
1. Light net Weight : 40% lighter than Metal
2. Better insulation: K value < 0.295 W/㎡ ℃
3. High in strength :
* ANTI-PRESSURE:>180MPa
* ANTI-CURVE: >220MPa
* ANTI-CURVE: >220MPa
CUT STRENGTH: 24.6MPa
4. Non-corrosion, non-pollution, anti-brine, acid and soda-resisting.
5. Easy assembly and repair at site ,3 work 4 hours for one box.
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Right elevation
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Interior elevation
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Amount Truck elevation
DESIGN & ORDER MEASUREMENTS REQUEST
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
BOX INSTALLATION PROCESS
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
FRP-PIE MODULAR PANEL FINISHED BOX SHOW CASE
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Windows Side Elevation
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Tail Elevation
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Door Side Elevation
FRP SANDWICH PANEL FINISHED BOX SHOW CASE
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Windows Side Elevation
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Tail Elevation
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
Door Side Elevation
Brief Instruction
GET INDUSTRY TRUCK CAMPERS
GET.6EXP. LIGHT AND STRONGER MODULAR BOX BY TRAILERBULL TRAILERBULL engineered expedition box types are available to accommodate your ideas about Expedition Vehicles. Though the basic needs of globetrotters are much the same, their demands on the vehicle itself differ lone traveler, twosome, family, class of driving license, destination, infrastructure, terrain, duration of the journey … All these criteria ultimately determine the optimum vehicle and the suitable chassis. GET.6EXP can translates these criteria into 3 Expedition box models geared to these different requirements thanks to our durable GRP Sandwich panel composite technology offers top performing strength. TRAILERBULL With different wall panels (FRP-Pie Modular Panel, FRP-Plast Sandwich Panel) to meet all the popular chassis and requirements in the world and already have proven themselves on the actual journeys of many satisfied cust.
2200mm Width FRP Insulated Sandwich Panel for RV Motorhome Expedition Recreational Vehicle
FAQ
Q '-What’s the material of your Truck Camper body?
A.- We can produce FRP (Fiberglass Reinforced Plastic), PPGI steel and Aluminum composite with XPS/PU insulation Sandwich panels for the truck camper box. The Core Material can be PU, XPS.

Q '- If want the price, what should offer us the information?
A.-You need offer us the material, size (LxWxH and the thickness of the panel) and quantity of the truck body as the basic
information. The sketch or the design drawing is much appreciated.

Q '-Can you pre-cut openings for windows and doors?
A.-We can offer this service with cost as we have embedded strengthen parts inside, but that will be confirmed before producing. your own Openings can easily be cut with a jigsaw and plastic rated blade, but the embedded strengthen parts cannot make. So if it will work in really bad expedition, you'd better let us pre-cut openings for windows and doors.


Q '-Can you do departure angles?
A.-Yes, we have two sizes of the box shape, one is the standard square shape, the other is the departure angle design. Please mark the desired angle (including dimensions) in the quoting template if you need.

Q '-Can you design subframes?
A.-We have the service of this, but you need supply the full chassis layout to us in advance.

Q '-Can I use different windows and doors than what’s listed on your specification?
A.-Yes. However, we highly recommend our windows and doors as they work in perfect balance with our camper bodies.

Q '-Can I order a camper body with an alcove?
A.-Yes. Please ask us for our alcove quoting template.

Q '–What’s included in the shipment?
A.-1. CKD type with All panels cut to size (other than departure angle), 2. CBU type with assembled box per your requirements.

Q '–Can you help with the interior layout?
A'–No. We are solely a camper body supplier, not a full-scale outfitter/design office.
