Dimension (Lx WxH) unloaded mm | | | 6110×2550×3200 | | |||
Approaching angle/Departure angle | | | 16/42 | | |||
Overhang(front/rear) (mm) | | | 1500/1110 | | |||
Wheel base (mm) | | | 3500 | | |||
Max speed km/h | | | 90 | | |||
Curb weight kg | | | 7180 | | |||
Max Payload kg | | | 38600 | | |||
Engine (Steyr technology, made in China) | Model | | WD615.47,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and intercooling, directly injection | | |||
| Fuel type | | Diesel | | |||
| Power max kw/rpm | | 273/2200(371HP) | | |||
| Emission | | EURO II | | |||
Fuel tanker capacity L | | | 400 | | |||
Transmission | | Model | HW19710; 10 forward & 2 reverse | | |||
Brake system | | Service brake | Dual circuit compressed air brake | | |||
| | Parking brake | spring energy, compressed air operating on rear wheels | | |||
Steering system | | Model | ZF- LHD | | |||
Front axle | | Steering with double T-cross section beam HF9 | | | |||
Rear axle | | Central reduction+hub reduction,cast axle housing ST16 | | | |||
Tyre | | 12R22.5 | | | |||
Cab | | HOWO76 Standard cab, all-steel forward control,55hydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers | | | |||
Electrical system | | Battery | | 2X12V/165Ah | |||
| | Alternator | | 28V-1500kw | |||
| | Starter | | 7.5Kw/24V |
