LR110 Rectifier Diode 100mA, 4μA QUIESCENT CURRENT CMOS LDO REGULATOR
LR110 Rectifier Diode 100mA, 4μA QUIESCENT CURRENT CMOS LDO REGULATOR
Specifications
Brand Name :
UTC-IC
Model Number :
LR110
Certification :
Original Factory Pack
Place of Origin :
Original
MOQ :
20pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
5200PCS
Delivery Time :
1 Day
Packaging Details :
please contact me for details
VIN :
7 V
PD :
500 mW
TJ :
125 ℃
TOPR :
-40 ~ +85 ℃
TSTG :
-65 ~ +150 ℃
Description

100mA, 4µA QUIESCENT CURRENT CMOS LDO REGULATOR

LR110 Rectifier Diode 100mA, 4μA QUIESCENT CURRENT CMOS LDO REGULATOR„ DESCRIPTION

The UTC LR1101 series are ultra-low quiescent current CMOS LDO (Low Dropout Voltage). Designed for battery-powered system, the low 4μA quiescent current makes it an ideal choice. The Range of the output voltage is from 1.5V ~ 5V with 0.1V per step. And the max output current is 100mA.

Wide range of available output fits most of applications. Built-in output current-limiting provide maximal protection against any fault conditions.

„ FEATURES

* 450mV typically dropout at 100mA

* Ultra-low quiescent current: 4μA

* Wide operating voltage ranges: 2V ~ 6V

* Thermal current limiting protection

* For stability only 1μF output capacitor is required

* High power supply rejection ratio

ABSOLUTE MAXIMUM RATINGS

PARAMETER SYMBOL RATINGS UNIT
Input Voltage VIN 7 V

Power Dissipation (TA = 25℃)

SOT-89

SOT-23

SOT-25

 PD

500 mW

250 mW

250 mW
Junction Temperature TJ 125 ℃
Operating Temperature TOPR TOPR -40 ~ +85 ℃
Storage Temperature TSTG -65 ~ +150 ℃

APPLICATION INFORMATION

Between VOUT and GND a 1μF (or larger) capacitor is recommended for stability. Without the capacitor the part may oscillate. When operating below -25℃ any type of capacitor can be used, but not Aluminum electrolytes. If there’s no limit the capacitance may be increased. Between VIN to GND a 1μF capacitor (or larger) should be placed.

LR110 Rectifier Diode 100mA, 4μA QUIESCENT CURRENT CMOS LDO REGULATOR
