Surface mount Si-Epitaxial PlanarTransistors BCP53
Surface mount Si-Epitaxial PlanarTransistors BCP53
Specifications
Brand Name :
anterwell
Model Number :
BCP53
Certification :
new & original
Place of Origin :
original factory
MOQ :
10pcs
Price :
negotiation
Payment Terms :
T/T, Western Union, PayPal
Supply Ability :
1000pcs
Delivery Time :
1 day
Packaging Details :
please contact me for details
Power dissipation – Verlustleistung :
1.3 W
Collector current – Kollektorstrom (DC) :
1 A
Peak Collector current – Koll.-Spitzenstrom :
1.5 A
Peak Base current – Basis-Spitzenstrom :
200 mA
Junction temperature – Sperrschichttemperatur :
150℃
Storage temperature – Lagerungstemperatur :
- 65…+ 150℃
Description

Power dissipation – Verlustleistung 1.3 W Surface mount Si-Epitaxial PlanarTransistors BCP53

Plastic case SOT-223

Kunststoffgehäuse

Weight approx. – Gewicht ca. 0.04 g

Plastic material has UL classification 94V-0

Gehäusematerial UL94V-0 klassifiziert

Standard packaging taped and reeled

Standard Lieferform gegurtet auf Rolle

Maximum ratings (TA = 25℃) Grenzwerte (TA = 25℃)

BCP 51 BCP 52 BCP 53
Collector-Emitter-voltage B open - VCE0 45 V 60 V 80 V
Collector-Base-voltage E open - VCB0 45 V 60 V 100 V
Emitter-Base-voltage C open - VEB0 5 V
Power dissipation – Verlustleistung Ptot 1.3 W 1 )
Collector current – Kollektorstrom (DC) - IC 1 A
Peak Collector current – Koll.-Spitzenstrom - ICM 1.5 A
Peak Base current – Basis-Spitzenstrom - IBM 200 mA
Junction temperature – Sperrschichttemperatur Tj 150℃
Storage temperature – Lagerungstemperatur TS - 65…+ 150℃

1 ) Mounted on P.C. board with 3 mm2 copper pad at each terminal

Montage auf Leiterplatte mit 3 mm2 Kupferbelag (Lötpad) an jedem Anschluß

Surface mount Si-Epitaxial PlanarTransistors BCP53
