Ultrafast Avalanche SMD bridge type rectifier diode , BYG20J - E3 - TR
Ultrafast Avalanche SMD bridge type rectifier diode , BYG20J - E3 - TR
Specifications
Brand Name :
VISHAY
Model Number :
BYG20J-E3-TR
Certification :
Original
Place of Origin :
Original
MOQ :
5 PCS
Price :
0.1USD
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
10000PCS/DAY
Delivery Time :
1 day
Packaging Details :
contact us for more details
Voltage :
200 V to 600 V
Features :
Low profile package
Description :
Matte tin plated leads
Temperature :
260 °C
Use :
Rectifier
Type :
diode
Description
BYG20J-E3-TR Diode Ultrafast Avalanche SMD Rectifier
FEATURES
• Low profile package
• Ideal for automated placement
• Glass passivated junction
• Low reverse current
• Soft recovery characteristics
• Ultrafast reverse recovery time
• Meets MSL level 1, per J-STD-020, LF maximum peak of
260 °C
• AEC-Q101 qualified
• Compliant to RoHS Directive 2002/95/EC and in
accordance to WEEE 2002/96/EC
MECHANICAL DATA
Case:
DO-214AC (SMA)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS compliant, commercial grade
Base P/NHE3 - RoHS compliant, AEC-Q101 qualified
Terminals:
Matte tin plated leads, solderable per
J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix
meets JESD 201 class 2 whisker test
Polarity:
Color band denotes the cathode end
PRIMARY CHARACTERISTICS
IF(AV)
1.5 A
VRRM 200 V to 600 V
IFSM 30 A
IR 1.0 μA
VF 1.4 V
trr 75 ns
ER 20 mJ
TJmax 150 °C

Ultrafast Avalanche SMD bridge type rectifier diode , BYG20J - E3 - TR

Ultrafast Avalanche SMD bridge type rectifier diode , BYG20J - E3 - TR
