IC 3 Pin Transistor 2SK3797 MOS Field Effect Transistor Stock Offer
IC 3 Pin Transistor 2SK3797 MOS Field Effect Transistor Stock Offer
Specifications
Brand Name :
ANTERWELL
Model Number :
2SK3797
Certification :
Original Factory Pack
Place of Origin :
Malaysia
MOQ :
10
Price :
negotiate
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
2500
Delivery Time :
Stock Offer
Packaging Details :
please contact me for details
Drain-source voltage :
600V
Drain-gate voltage :
600V
Main Line :
IC components, Transistor, Diode, Module,Capacitor etc
Temperature :
-50~150 °C
Package :
TO-220
Description

IC 3 Pin Transistor 2SK3797 MOS Field Effect Transistor Stock Offer

2SK3797 Field Effect Transistor Silicon N-Channel MOS Type IC 3 Pin Transistor 2SK3797 MOS Field Effect Transistor Stock Offer

Switching Regulator Applications

• Low drain-source ON resistance: RDS (ON) = 0.32Ω (typ.)

• High forward transfer admittance: |Yfs| = 7.5 S (typ.)

• Low leakage current: IDSS = 100 μA (VDS = 600 V)

• Enhancement model: Vth = 2.0~4.0 V (VDS = 10 V, ID = 1 mA)

Maximum Ratings (Ta = 25°C)

Characteristic Symbol Rating Unit
Drain-source voltage VDSS 600 V
Drain-gate voltage (RGS = 20 kΩ) VDGR 600 V
Gate-source voltage VGSS ±30 V

Drain current DC

Pulse (t = 1 ms)

 ID 13 A
IDP 52
Drain power dissipation (Tc = 25°C) PD 50 W
Single pulse avalanche energy EAS 1033 mJ
Avalanche current AR 13 A
Repetitive avalanche energy EAR 5.0 mJ
Channel temperature Tch 150 °C
Storage temperature range Tstg -50-150 °C

Thermal Characteristics

Characteristic Symbol Max Unit
Thermal resistance, channel to case Rth (ch-c) 2.5 w/ °C
Thermal resistance, channel to abinent Rth (ch-a) 62.5 w/ °C

Note 1: Ensure that the channel temperature does not exceed 150°C during use of the device.

Note 2: VDD = 90 V, Tch = 25°C (initial), L = 10.7 mH, IAR = 13 A, RG = 25 Ω

Note 3: Repetitive rating: pulse width limited by maximum channel temperature This transistor is an electrostatic-sensitive device. Handle with care.
