Original IC Electronic Components 74HC585D Dual AND OR Gate CMOS Device
Original IC Electronic Components 74HC585D Dual AND OR Gate CMOS Device
Specifications
Brand Name :
Anterwell
Model Number :
74HC585D
Certification :
Original Factory Pack
Place of Origin :
Thailand
MOQ :
5pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
2200PCS
Delivery Time :
1 Day
Packaging Details :
please contact me for details
FEATURES :
Output capability: standard
FEATURES2 :
ICC category: SSI
Shipment: :
DHL, Fedex, TNT, EMS etc
Main Line: :
Ic,module,transistor,diodes,capacitor,resistor etc
Package :
SOP-16
Factory Pack :
Reel
Description

Original IC Electronic Components 74HC585D Dual AND OR Gate CMOS Device

74HC58 Dual AND-OR gate

FEATURES

• Output capability: standard

• ICC category: SSI

GENERAL DESCRIPTION

The 74HC58 is a high-speed Si-gate CMOS device and is pin compatible with low power Schottky TTL (LSTTL). It is specified in compliance with JEDEC standard no. 7A.

The “58” provides two sections of AND-OR gates. One section contains a 2-wide, 3-input (1A to 1F) AND-OR gate and the second section contains a 2-wide, 2-input (2A to 2D) AND-OR gate.

QUICK REFERENCE DATA

SYMBOL PARAMETER CONDITIONS TYPICAL HC UNIT
tPHL/ tPLH

propagation delay

1n to 1Y

2n to 2Y

CL = 15 pF;

VCC = 5 V

 11 9

ns

ns

CI input capacitance 3.5 pF
CPD power dissipation capacitance per gate notes 1 and 2 18 pF

Notes

1. CPD is used to determine the dynamic power dissipation (PD in µW): PD = CPD × VCC2 × fi + ∑ (CL × VCC2 × fo) where: fi = input frequency in MHz fo = output frequency in MHz CL = output load capacitance in pF VCC = supply voltage in V ∑ (CL × VCC2 × fo) = sum of outputs

2. For HC the condition is VI = GND to VCC
