popular Integrated Circuit Chip TLE4270-2G 5-V Low Drop Fixed Voltage Regulator
popular Integrated Circuit Chip TLE4270-2G 5-V Low Drop Fixed Voltage Regulator
Specifications
Model Number :
TLE4270-2G
Certification :
new & original
Place of Origin :
original factory
MOQ :
10pcs
Price :
Negotiate
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
7300pcs
Delivery Time :
1 day
Packaging Details :
Please contact me for details
Junction temperature :
150°C
Storage temperature :
-50 to 150°C
Input voltage :
6 to 42V
package :
Reel
Description

TLE4270-2G 5-V Low Drop Fixed Voltage Regulator


popular Integrated Circuit Chip TLE4270-2G 5-V Low Drop Fixed Voltage RegulatorFeatures

• Output voltage tolerance ≤ ±2%
• 650 mA output current capability
• Low-drop voltage
• Reset functionality
• Adjustable reset time
• Suitable for use in automotive electronics
• Integrated overtemperature protection
• Reverse polarity protection
• Input voltage up to 42 V
• Overvoltage protection up to 65 V (≤ 400 ms)
• Short-circuit proof
• Wide temperature range
• ESD protection: ±2kV HBM1)
• Green Product (RoHS compliant)
• AEC Qualified

Functional Description

This device is a 5-V low drop fixed-voltage regulator. The maximum input voltage is 42 V (65 V, ≤ 400 ms). Up to an input voltage of 26 V and for an output current up to 650 mA it regulates the output voltage within a 2% accuracy. The short circuit protection limits the output current of more than 650 mA. The device incorporates overvoltage protection and a temperature protection which turns off the device at high temperatures.

Absolute Maximum Ratings

popular Integrated Circuit Chip TLE4270-2G 5-V Low Drop Fixed Voltage Regulator
popular Integrated Circuit Chip TLE4270-2G 5-V Low Drop Fixed Voltage Regulator
popular Integrated Circuit Chip TLE4270-2G 5-V Low Drop Fixed Voltage Regulator
popular Integrated Circuit Chip TLE4270-2G 5-V Low Drop Fixed Voltage Regulator

Stock Offer (Hot Sell)

Part No. Quantity Brand D/C Package
LM3488MM 14816 TI 16+ MSOP-8
LM34DZ 5112 TI 14+ TO-92
LM3526MX-L 16692 TI 16+ SOP-8
LM358ADR 71000 TI 15+ SOP-8
LM358AMX 21853 FSC 16+ SOP-8
LM358APWR 16686 TI 13+ TSSOP-8
LM358DR 57000 TI 16+ SOP-8
LM358DR2G 25000 ON 16+ SOP-8
LM358MX 10438 FSC 08+ SOP-8
LM358S-13 73000 DIODES 11+ SOP-8
LM35DMX 7069 NS 13+ SOP-8
LM35DZ 8018 TI 16+ TO-92
LM3671MFX-1.8 9322 NS 16+ SOT23-5
LM384N 6765 NS 86+ DIP
LM385D-2.5 16757 ON 17+ SOP-8
LM385M3X-2.5 10509 TI 15+ SOT23-3
LM386MX-1 8505 NS 16+ SOP-8
LM3886T/NOPB 3500 TI 15+ ZIP-11
LM3886TF 2569 NS 14+ ZIP-11
LM393MX 21332 NSC 13+ SOP-8
LM4040A25IDBZR 61000 TI 15+ SOT23-3
LM4040AIM3-3.0 8166 MAXIM 16+ SOT-23
LM4040BIM3-3.0 21924 TI 13+ SOT23-3
LM4040C20IDBZR 4600 TI 15+ SOT23-5
LM4040DIM3X-2.5 16828 TI 16+ SOT23-3
LM4040DYM3-2.5 21995 MICREL 15+ SOT23-3
LM4050BIM3X-2.5 9293 TI 17+ SOT23-3
LM431ACM3X 12971 NS 16+ SOT-23
LM4670SD 9264 NS 06+ QFN
LM4853MM 12686 TI 14+ MSOP
