FAN8303MX Ic Electronic Components Chips Non-Synchronous Step-Down DC/DC Regulator
FAN8303MX Ic Electronic Components Chips Non-Synchronous Step-Down DC/DC Regulator
Specifications
Brand Name :
Anterwell
Model Number :
FAN8303MX
Certification :
new & original
Place of Origin :
original factory
MOQ :
10pcs
Price :
Negotiate
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
8000pcs
Delivery Time :
1 day
Packaging Details :
Please contact me for details
Supply Voltage, VIN to GND :
25 V
Switch Voltage, SW to GND :
-0.3 to Vin+0.3 V
Boost Voltage :
Vsw + 6 V
Feedback Voltage :
-0.3 to 6.0 V
Operating Junction Temperature :
-40 to +125 °C
Storage Temperature :
-65 to +150 °C
Description

FAN8303

2A 23V Non-Synchronous Step-Down DC/DC Regulator

Features ƒ

  • 2A Output Current ƒ
  • 0.22Ω Internal Power MOSFET Switch ƒ
  • Wide 5V to 23V Operating Input Range ƒ
  • Output Adjustable from 0.6 to 20V ƒ
  • Stable with Low ESR Output Ceramic Capacitors ƒ
  • Up to 90% Efficiency ƒ
  • Less than 40µA Shutdown Current ƒ
  • Fixed 370kHz Frequency ƒ
  • Thermal Shutdown with Hysteresis ƒ
  • Cycle-by-Cycle Over-Current Protection ƒ
  • Available in 8-Pin SOIC Package

Applications ƒ

  • Set-Top Box ƒ
  • DSL and Cable Modems ƒ
  • Distributed Power Systems ƒ
  • Consumer Appliances (DVD) ƒ
  • Auxiliary supplies

Description

The FAN8303 is a monolithic, non-synchronous, stepdown (buck) regulator with internal power MOSFETs. It achieves 2A continuous output current over a wide input supply range with excellent load and line regulation. Current-mode operation provides fast transient response and eases loop stabilization. Fault condition protection includes cycle-by-cycle current limiting and thermal shutdown. The regulator draws less than 40µA shutdown current. FAN8303 requires a minimum number of readily available standard external components.

External compensation, enable, and programmable soft-start features allow design optimization and flexibility. Cycle-by-cycle current limit, frequency foldback, and thermal shutdown provide protection against shorted outputs.

FAN8303MX Ic Electronic Components Chips Non-Synchronous Step-Down DC/DC Regulator

Absolute Maximum Ratings

Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be operable above the recommended operating conditions and stressing the parts to these levels is not recommended. In addition, extended exposure to stresses above the recommended operating conditions may affect device reliability. The absolute maximum ratings are stress ratings only. All voltage values, except differential voltages, are given with respect to the network ground terminal. Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device

Symbol Parameter Min. Max. Unit
VIN Supply Voltage, VIN to GND 25 V
VSW Switch Voltage, SW to GND -0.3 VIN+0.3 V
VBS Boost Voltage VSW + 6 V
VFB Feedback Voltage -0.3 6.0 V
VEN Enable Voltage -0.3 6.0 V
VCOMP Compensation Voltage -0.3 6.0 V
VSS Soft-Start Voltage -0.3 6.0 V
ΘJA Thermal Resistance, Junction-Air 105 °C/W
ΘJC Thermal Resistance, Junction-Case 40 °C/W
TJ Operating Junction Temperature -40 +125 °C
TL Lead Temperature (Soldering, 5 Seconds) +260 °C
TSTG Storage Temperature Range -65 +150 °C
ESD Electrostatic Discharge Protection Level Human Body Model, JEDEC JESD22-A114 3.0 kV
Charged Device Model, JEDEC JESD22- C101 2.5
