ACT4065ASH-T High Input 2A Step Down Converter led circuit board design

ACT4065ASH-T High Input 2A Step Down Converter led circuit board designFEATURES

• 2A Output Current

• Up to 95% Efficiency

• 6.0V to 30V Input Range

• 210kHz Switching Frequency

• Adjustable Output Voltage

• Cycle-by-Cycle Current Limit Protection

• Thermal Shutdown Protection

• Frequency Foldback at Short Circuit

• Stability with Wide Range of Capacitors, Including Low ESR Ceramic Capacitors

APPLICATIONS

• TFT LCD Monitors

• Portable DVDs

• Car-Powered or Battery-Powered Equipments

• Set-Top Boxes

• Telecom Power Supplies

• DSL and Cable Modems and Routers

• Termination Supplies

GENERAL DESCRIPTION

The ACT4065A is a current-mode step-down DC/DC converter that generates up to 2A output current at 210kHz switching frequency.

The ACT4065A is highly efficient with peak efficiency at 95% when in operation. Protection features include cycle-by-cycle current limit, thermal shutdown, and frequency foldback at short circuit.

The ACT4065A is available in SOP-8 package and requires very few external devices for operation.
