HCF4081M013TR Ic Integrated Circuit CMOS Gates Quad 2 Input And Gate
HCF4081M013TR Ic Integrated Circuit CMOS Gates Quad 2 Input And Gate
Specifications
Brand Name :
Anterwell
Model Number :
HCF4081M013TR
Certification :
new & original
Place of Origin :
original factory
MOQ :
10pcs
Price :
Negotiate
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
8600pcs
Delivery Time :
1 day
Packaging Details :
Please contact me for details
Supply Voltage :
-0.5 to +22 V
DC Input Voltage :
-0.5 to VDD + 0.5 V
DC Input Current :
± 10 mA
Power Dissipation per Package :
200 mW
Operating Temperature :
-55 to +125 °C
Storage Temperature :
-65 to +150 °C
Description

HCF4081M013TR Ic Integrated Circuit CMOS Gates Quad 2 Input And Gate

■ MEDIUM SPEED OPERATION: tPD = 60ns (Typ.) at 10V

■ QUIESCENT CURRENT SPECIFIED UP TO 20V

■ 5V, 10V AND 15V PARAMETRIC RATINGS

■ INPUT LEAKAGE CURRENT

II = 100nA (MAX) AT VDD = 18V TA = 25°C

■ 100% TESTED FOR QUIESCENT CURRENT

DESCRIPTION

The HCF4081B is a monolithic integrated circuit fabricated in Metal Oxide Semiconductor technology available in DIP and SOP packages. The HCF4081B QUAD 2 INPUT AND GATE provide the system designer with direct implementation of the AND function and supplement the existing family of CMOS gates.

ABSOLUTE MAXIMUM RATINGS

Symbol Parameter Value Unit
VDD Supply Voltage -0.5 to +22 V
VI DC Input Voltage -0.5 to VDD + 0.5 V
II DC Input Current ± 10 mA
PD Power Dissipation per Package 200 mW
Power Dissipation per Output Transistor 100 mW
Top Operating Temperature -55 to +125 °C
Tstg Storage Temperature -65 to +150 °C

Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these conditions is not implied.

All voltage values are referred to VSS pin voltage.

HCF4081M013TR Ic Integrated Circuit CMOS Gates Quad 2 Input And Gate

ORDER CODES

PACKAGE TUBE T & R
DIP HCF4081BEY
SOP HCF4081BM1 HCF4081M013TR

PIN CONNECTION

HCF4081M013TR Ic Integrated Circuit CMOS Gates Quad 2 Input And Gate

HCF4081M013TR Ic Integrated Circuit CMOS Gates Quad 2 Input And Gate
