Specifications
Brand Name :
Bicheng Enterprise Limited
Model Number :
BIC-0418-V4.18
Certification :
UL
Place of Origin :
China
MOQ :
1
Price :
USD40~50
Payment Terms :
T/T, Paypal
Supply Ability :
45000 pieces per month
Delivery Time :
5-6 working days
Packaging Details :
Vacuum
Number of Layers :
4
Board Material :
Polyimide 25µm,ITEQ
Board Thickness :
0.20mm
Surface/Inner layer Cu thickness :
35 µm /35 µm
Surface Finish :
Immersion Gold
Coverlay Colour :
Yellow coverlay / Green solder mask
Color of Silkscreen :
White
Function :
100% Pass electrical test
Description

Product profile

1.1 General description


This is a type of 4 layer flexible printed circuit for the application of Wireless Intercom

at 0.2mm thick. The base laminate is from ITEQ, It’s fabricated per IPC 6012 Class 2

using supplied Gerber data.


1.2 Features and benifits

A. Excellent flexibility
B. Reducing the volume
C. Weight reduction
D. Consistency of assembly
E. Increased reliability
F. Controllability of electrical parameter design
G. The end can be whole soldered
H. Material optionality
I. Low cost
J. Continuity of processing
K. Small quantity, prototypes and production.
L. Engineering design prevents problems from occurring in pre production.

1.3 Application


Touch screen, Consumer card reader soft board, Tablet keypad flex board


1.4 Parameter and data sheet

Size of Flexible PCB 70.58 X 120.37mm
Number of Layers 4
Board Type Flexible PCB
Board Thickness 0.20mm
Board Material Polyimide 25µm
Board Material Supplier ITEQ
Tg Value of Board Material 60℃
PTH Cu thickness ≥20 µm
Inner Iayer Cu thicknes 35 µm
Surface Cu thickness 35 µm
Coverlay Colour Yellow coverlay / Green solder mask
Number of Coverlay 2
Thickness of Coverlay 25 µm
Stiffener Material no
Stiffener Thickness N/A
Type of Silkscreen Ink IJR-4000 MW300
Supplier of Silkscreen TAIYO
Color of Silkscreen White
Number of Silkscreen 1
Peeling test of Coverlay No peelable
Legend Adhesion 3M 90℃ No peeling after Min. 3 times test
Surface Finish Immersion Gold
Thickness of Nickle/Gold Au: 0.03µm(Min.); Ni 2-4µm
RoHS Required Yes
Famability 94-V0
Thermal Shock Test Pass, -25℃±125℃, 1000 cycles.
Thermal Stress Pass, 300±5℃,10 seconds, 3 cycles. No delamination, no blistering.
Function 100% Pass electrical test
Workmanship Compliance with IPC-A-600H & IPC-6013C Class 2
