Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Flexible PCBs board prototype Single-sided flexible PCBs 0.15mm thick Circuit Board Assembly Polyimide PCBs for counter keypad
Specifications
Brand Name :
Bicheng Enterprise Limited
Model Number :
BIC-0402-V4.02
Certification :
UL
Place of Origin :
China
MOQ :
1
Price :
USD40~50
Payment Terms :
T/T, Paypal
Supply Ability :
45000 pieces per month
Delivery Time :
5-6 working days
Packaging Details :
Vacuum
Board Material :
Polyimide 25µm Shengyi 60℃
Board Thickness :
0.15mm
Surface Cu thickness :
35 µm
Surface Finish :
Immersion Gold
Coverlay Colour :
Yellow
Color of Silkscreen :
White
Function :
100% Pass electrical test
Description

Product profile

1.1 General description

This is a type of flexible printed circuit for the application of counter keypad. It’s a sinlge

layer FPC at 0.15mm thick. The base laminate is from Shengyi, It’s fabricated per IPC

6012 Class 2 using supplied Gerber data. Polyimide stiffner is applied on the inserting

head.

1.2 Features and benifits

A. Excellent flexibility
B. Reducing the volume
C. Weight reduction
D. Consistency of assembly
E. Increased reliability
F. Controllability of electrical parameter design
G. The end can be whole soldered
H. Material optionality
I. Low cost
J. Continuity of processing
K. Great customer service
L. Delivery on time: >98%

1.3 Application

  • Contact belt of inkjet printer,
  • Industrial control temperature controller soft board,
  • Tablet keypad flex board

1.4 Parameter and data sheet

Size of Flexible PCB 64.23 X 35.74mm
Number of Layers 1
Board Type Flexible PCB
Board Thickness 0.15mm
Board Material Polyimide 25µm
Board Material Supplier Shengyi
Tg Value of Board Material 60℃
PTH Cu thickness ≥20 µm
Inner Iayer Cu thicknes N/A
Surface Cu thickness 35 µm
Coverlay Colour Yellow
Number of Coverlay 2
Thickness of Coverlay 25 µm
Stiffener Material Polyimide Stiffner, 3M Tape
Stiffener Thickness 0.2mm
Type of Silkscreen Ink IJR-4000 MW300
Supplier of Silkscreen TAIYO
Color of Silkscreen White
Number of Silkscreen 1
Peeling test of Coverlay No peelable
Legend Adhesion 3M 90℃ No peeling after Min. 3 times test
Surface Finish Immersion Gold
Thickness of Nickle/Gold Au: 0.03µm(Min.); Ni 2-4µm
RoHS Required Yes
Famability 94-V0
Thermal Shock Test Pass, -25℃±125℃, 1000 cycles.
Thermal Stress

Pass, 300±5℃,10 seconds, 3 cycles.

No delamination, no blistering.
Function 100% Pass electrical test
Workmanship Compliance with IPC-A-600H & IPC-6013C Class 2
