Product Name :
A2211T Terminal
Pitch :
2.00mm
Used in :
A2006 and A2211 series housing
Material :
Phosphor Bonze
Wire range :
AWG#22-#28
Fire-protection rating :
UL 94V-0
Finish :
Tin-plated
Description

Wire to board connector Pitch 2.00mm Phoshor Bronze Tin-plated Battery terminal connector

Description:

1.Terminals E-Stamping before Tin-plated ,Tin-plated we calling A2211-TPe, Minimum packing quantity is 4,000pcs/Reel. The daily production capacity is 200 to 300 KPCS.

2.Terminals' wire range :AWG #22--#28 ,insulation OD is1.4mm(Max)

Specifications:

Test Description Procedure Requirement

Contact Resistance

 Mate connectors, measure by dry circuit, 20mV max., 10mA.(Based upon JIS C5402 5.4) 10mΩ (Max.)
Insulation Resistance Mate connectors, apply 500V DC between adjacent terminal or ground. (Based upon JIS C5402 5.2/MIL-STD-202 Method 302 Cond. B) 1000MΩ (Min.)
Dielectric Withstanding Voltage Mate connectors, apply 1000V AC (rms) for 1 minute between adjacent terminal or ground. (Based upon JIS C5402 5.1/MIL-STD-202 Method 301) No Breakdown.
Contact Resistance on Crimped Portion Crimp the applicable wire on to the terminal, measure by dry circuit, 20mV (Max.)., 10mA.. 5mΩ (Max.)

Electrical:

Voltage rated 250V AC ,DC
Current rated 2A AC,DC
Withstand voltage 800VAC/minute
Insulation resistance 1000MΩ Min
Contact resistance 30mΩ Max
Operating temperature -25°C~85°C

Reference informations:

Material Wafer: PA66 , UL94V-0

Pin:Brass/Tin-plated

Mates with A2501 series single row housing

Drawing:
