Small Investment Tissue Paper Folding Machine 380V 50Hz 1000-1500pcs /Min
Small Investment Tissue Paper Folding Machine 380V 50Hz 1000-1500pcs /Min
Small Investment Tissue Paper Folding Machine 380V 50Hz 1000-1500pcs /Min
Small Investment Tissue Paper Folding Machine 380V 50Hz 1000-1500pcs /Min
Specifications
Place of Origin :
Fujian, China
Brand Name :
EAST
Certification :
ISO9001
Packaging Details :
Pallet
MOQ :
1 SET
Price :
$15,800.00/set
Payment Terms :
L/C, T/T
Supply Ability :
20 sets per month
Delivery Time :
50days
Model Number :
3L
Dimension(L*W*H) :
6.2*2.6*1.8m
Voltage :
380V 50Hz
Weight :
3.0t
Warranty :
2 years
Production Capacity :
1000-1500pcs /min, 1000-1500pcs/min
Core Components :
PLC, Pump
max.rewinding diameter :
690mm (width)
electric power :
7.5kw
Dimension :
8600 X 1300X 1800mm
Raw material jumbo roll size :
1200mm
Description

Machine Features

1.Automatic counting points a whole row output.

2.Helical blade shear,vacuum adsorption folding.

3.Stepless speed regulation unwind and can adapt to rewind high -low tension paper material .

4.Adopt PLC computer programing control ,pneumatic paper and easy to operate.

5.Frequency conversion control ,saves enery.

6.The product width is adjustable ,to meet different market requirement.

7.Supporting paper rolling pattern device ,pattern obvious,flexible to market demand,(pattern by guests choose)

8.It can make "V" type single layer towel and two layers glue lamination.(optional)

Machine Technical Parameter

Finished product size 220L*220mm (other size are available)
Raw material size 690mm
speed 0-100m/min Depending on the machine modle
Programmable controller Plc computer
Folding type Vacuum suction "Z" fold
Transmission unit Timing belt
Counter lnk marked
Embossing unit Steel to steel
Slitting unit Pneumatic dot slitting
Total power 15kw
Pneumatic system 3hp air compressor .mini air pressure 5 kg/cm
Dimension Depends on Machine Modle
Weight Depend on the size and configure

Small Investment Tissue Paper Folding Machine 380V 50Hz 1000-1500pcs /Min

Small Investment Tissue Paper Folding Machine 380V 50Hz 1000-1500pcs /Min


FAQ

Q: Can you provide the installation videos?

A: Yes, we will provide.


Q: What's the production time?

A: Generally it is 40-60 working days, it depends on your customized requirements.

Q: How long is your warranty?

A: One year of the machine, wearing parts not included.


Q: Can your company do customized machine?

A: Yes we can. We have 3 experienced engineers to support customized designs.


Q: How about your after-sales services?

A: We offer online instructions or onsite if needed.
