3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min
3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min
3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min
3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min
3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min
3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min
Specifications
Place of Origin :
Fujian, China
Brand Name :
EAST
Certification :
ISO9001
Packaging Details :
wooden case
MOQ :
1 SET
Price :
$35000/set
Payment Terms :
L/C, T/T
Supply Ability :
20sets per month
Delivery Time :
35-40days
Model Number :
3000mm
Showroom Location :
United States, Italy, Philippines, Brazil, Peru, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Morocco, Kenya, Argentina, South Korea, Chile, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzst
Processing Type :
Paper Rewinding Machine
Applicable roll quantity :
12~16GSM(2ply/3 ply)tissue paper
Production Capacity :
180-300m/min
Dimension(L*W*H) :
6.2*2.6*1.8m
Weight :
3.0t
Max. workable width :
3000mm
Machinery Test Report :
Provided
Core Components :
PLC, Pump
Warranty of core macine :
1 year
Port :
XIAMEN
Description

3000mm Toilet Paper Making Machine With Factory Price

Machine Advantage

Jumbo roll slitting and rewinding machine means sltting material paper into maxi roll toilet paper,Mainly used for large public toilet ,such as the toilet of hotel ,airport

1. Adopts international advanced PLC programmable controlling technique,man-machine interface operation,data set and parametric fault shows on touch screen.

2. Adopts 4 pieces high Precision spiral knives,low noise,clear perforation,adopt gearbox to have bigger range.

3. Two wall type back stands,pneumatic lifting system,with wide driving flat belts,each jumbo roll can be adjusted independently.

4.Deliver paper with pneumatic wide belt,with separte tension control device in each roll of raw paper.

5,Adopt jog buttons for drawing the operation is more simple and safe

Equipment Parameter

Control Unit Electrical control,Scheider Control buttons,Taiwan Proximity switch

Maximum material width

 3000mm

Maximum material diameter

 1200mm

Maximum rewinding diameter

 300mm
Vacuum control 1 set roots vacuum pump of 22KW(Taiwan)
Pneumatic system Air pressure:> 4kg/cm2 (provided by buyer)

3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min

3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min

3000mm Toilet Paper Jumbo Roll Slitter Rewinder 180-300m/Min

FAQ

Q: Can you provide the installation videos?

A: Yes, we will provide.


Q: What's the production time?

A: Generally it is 40-60 working days, it depends on your customized requirements.

Q: How long is your warranty?

A: One year of the machine, wearing parts not included.


Q: Can your company do customized machine?

A: Yes we can. We have 3 experienced engineers to support customized designs.


Q: How about your after-sales services?

A: We offer online instructions or onsite if needed
