Wave Spring Military Circular Connectors Accessories High Wear Resistance Long Lifespan
Wave Spring Military Circular Connectors Accessories High Wear Resistance Long Lifespan
Wave Spring Military Circular Connectors Accessories High Wear Resistance Long Lifespan
Wave Spring Military Circular Connectors Accessories High Wear Resistance Long Lifespan
Wave Spring Military Circular Connectors Accessories High Wear Resistance Long Lifespan
Wave Spring Military Circular Connectors Accessories High Wear Resistance Long Lifespan
Specifications
Brand Name :
RAYMO
Model Number :
WSO 102 A051 140+
Certification :
REACH/ CE/ ISO9000:2015/ ROHS/ SGS
Place of Origin :
SHENZHEN,CHINA
MOQ :
5Piece/Pieces
Price :
Negotiable
Payment Terms :
Western Union, L/C, D/A, D/P, T/T
Supply Ability :
10000Pieces/ Month
Delivery Time :
5-7wds
Packaging Details :
Plastic Bag & Carton
Series :
Waterproof circular connectors
Shell model :
Fischer WSO elbow connectors
Shell size :
0F/102,1F/103,AF/1031,2F/104
Contact no. :
2,3,4,5,7,9pins(2-19pins for other shell)
Connects type :
PPS/PEEK insulator with solder contacts
Application :
Test and Measurement
Description

WSO Fischer elbow cable connector, waterproof IP68,WSO 102 A051 140 2pins 102 103 1031 104

Parts No.:RM-WSO-0F1S-P02JS50= WSO 102 A051 140+

Description
1 100% substitute with original Fischer WSO elbow cable plug
2 right angle 2pins,male solder contacts with black shellIP68 circular cable connector
3 shell size 102,103,1031 and 104
4 Sealed to IP68 and Hermetic
5 360° EMC shield
6 Available Solder,PCB or right angle PCB contacts
7 Robust and shock resistant designs

RAYMO is a manufacturer that:

♣ Manufacturing & exporting various metal & plastic circular connectors and cable assembly

♣ All prcts can be 100% compatible with original LEMO • FISCHER • • HIROSE • BINDERS and Military 38999

♣ Cable Assembly can be designed according customer real needs

♣ All the prcts we got CE, ROHS, SGS,ISO9000 certificate

♣ OEM connector and Cable assembly

• All the items can work normally after 5000 times mating

We can make all types of cables and connectors as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-sub, USB, RJ45, Dtap, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO

Series

contact no.

0F/102 series

2,3,4,5,6,7,9

1F/103 series

2,3,4,5,6,7,8,10,12

AF/1031 series

10,12,15,19

2F/104 series

2,3,4,5,6,8,16,19

Technical Characteristics
Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >144hr
Climatical Category 50/175/21 Shielding (min) > 75 dB [ at 10 MHz]
> 40 dB [ at 1 GHz]
IP Rating IP 68 Certifications ISO9001 CE ROHS2.0 SGS

Wave Spring Military Circular Connectors Accessories High Wear Resistance Long Lifespan

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Why choose us:

  • 100% compatible lemo connector
  • Help you save at least 50% cost
  • Cable assembly offer,help you save prction time

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
