IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130
Specifications
Brand Name :
RAYMO
Model Number :
RM-S 1031A019-130
Certification :
ROHS2.0, REACH, CE, SGS, ISO9001:2015
Place of Origin :
SHENZHEN, CHINA
MOQ :
1PC
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000pcs per week
Delivery Time :
3-5 working days
Packaging Details :
PE BAG+ CARTON
Shell size :
0F(102), 1F(103), AF(1031), 2F(104), 3F(105)
Insulator Material :
PEEK, PPS
Gender :
Female
Pin :
2-19pins
IP Rating :
IP68
Description
Description of Connector

RM-F Series Core series IP68 waterproof Metal circular push pull connectors

Part No.:

S.103A062-140 / RM-WSO-1F1S-P12JS52

Prct Description:

1F(=103) size,S model cable mounted straight plug connector, 12pin male contact, code 1, black-color chrome plated shell in brass, 52 size cable collet for 4.2-5.2mm

Key Features
  • IP68 ranking
  • 3 different code
  • Miniature circular connector
  • Miniest circular connectors
  • High corrosion resistance
  • Hermetic receptacle structure can be suitable for equipment requiring air
Technical Characteristics

Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >144 hr
Climatical Category 50/175/21 Shielding (min) > 95 dB [ at 10 MHz], > 80 dB [ at 1 GHz]
IP Rating IP 68 Endurance(shell) ≥5000 mating cycles

Applications
  • Aviation
  • Communications
  • Industrial Control
  • Information Systems
  • Military
  • Test and Measurement
  • Data Acquisition
  • Data Transfer Equipment
  • Sensor Systems Instrumentation
  • Analysis Application
Prct Picture
IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130

IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130

Our Exhibition
2020.11 Electrnica Munich, Germany
2020.9 Testing Expo, Shanghai
2019 9.24-9.26 Testing Expo, Shanghai
2018 11.12-11.15 Electronica Munich, Germany
2017 9.11-9.16 NAB Show,Netherlands
2016 4.11-4.15 HK Fair
2015 10.2-10.7 ICEEB, Brasil
2014 10.11-10.15 HK Fair
2014 4.11-4.15 HK Fair

Our Company

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen that is a leading companyin the design, manufacturing and distribution of high-performance connectors and cable assembly solutions.Known for their quality, ruggedness and excellent sealing, our prcts prove to be reliable in the most demanding environments.

IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130

Why Choose US
  • 100% compatible with lemo, , fischer connector
  • Help you save at least 50% cost
  • All the prcts we got CE, ROHS, SGS,ISO9000 certificate
  • Fast delivery: 2-15 working days
  • Cable assembly offer, help you save prction time

IP68 Waterproof Metal circular Connector, cable mounted str plug Fischers S 1031A019-130

RFQ

1.What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
2. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them beforeshipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
3. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular push pull connectors and cable assembly since 2010.
4. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
5. Free sample :
RAYMO: Available. Any needs, please contact us:
6. What about the delivery time?
Raymo: sample for 1-2 working days, mass prction for 5-10 working days.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
