Specifications
Brand Name :
RAYMO
Model Number :
PFG.1B.302.CLLD52Z
Certification :
CE ROHS2.0 ISO9001 REACH
Place of Origin :
SHENZHEN,CHINA
MOQ :
1 Piece/Pieces
Price :
Negotiable
Payment Terms :
T/T, D/A, D/P,L/C, MoneyGram, Western Union
Supply Ability :
5000Pieces/ Week
Delivery Time :
5-7working days
Packaging Details :
Plastic Bag & Carton
Prct Name :
Metal circular push pull connector
Model :
FGG cable mout plug , nut for a bend relief
Shell size :
1B
Contact no. :
2pin male contact
Insulator :
PPS, PEEK
Shell Color :
Silver chrome black chrome
Description
Lemos Metal Circular Push Pull Connector FPG.1B.302.CLLD52Z Cable Socket

  • PFG.1B.302.CLLD52Z

  • Cable mount Socket, 1B series shell size, 2pin female contact, 52cable collet for OD4.2-5.2mm cable, nut for a bend relief, 1 key, 0 degree, brass shell with natural chrome plated

  • make with cable by overmoudling, like HMDI, DB9, D-SUB, RS232,

  • cable can be twisted wire depend on custom options

Main Features
  • Push pull locking metal connector B-series connector, cable to cable connector, free socket, inline connector
  • can be 100% compatible with original lemo connector
  • can be with different degree , such us 30, 45, 60, 90, 135,
  • can plated with white or black chrome,
  • 360 angle screening for full EMC shielding.
  • ISO:9001-2015 CE RoHS2.0 SGS REACH
Technical Charactueristics

Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >144hr
Climatical Category 50/175/21 Shielding (min) > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating IP 68 Endurance(shell) 5000 mating cycles

PHOTOS

Compatible Straight Circular Push Pull Connectors High Reliability For OD 4.2-5.2mm Cable

RAYMO Company Intrce

As manufacturer located in Shenzhen, focusing on manufacturing connectors and cable assemblies serive more than 150 countries since 2010.
Raymo Connectors is committed to working closely with its customers to equip their application with the most appropriate connector and cable system.
Our prct range comprises over 3,000 standard items and we are always prepared to develop customized solutions for specific requests.
RAYMO Prcts Applicaiton
  • Army, Navy, Air Force, Gendarmerie, Ministry of National Defense and Coast Guard
  • Midcal equipments like Disposable equipment
  • Test & measurement like Data acquisition
  • Broadcast, like HD and SD cameras
  • Energy, like Renewable energies
  • Extreme, such as Sailboat racing
RAYMO Exhibitions

  • 2020.11 Electronica Munich, Germany

  • 2019.9.13-9.15 Testing Expo, Shanghai

  • 2018 11.12-11.15 Electronica Munich, Germany

  • 2017 9.11-9.16 NAB Show,Netherlands

  • 2016 4.11-4.15 HK Fair

  • 2015 10.2-10.7 ICEEB, Brasil

  • 2014 10.11-10.15 HK Fair

Why Choose a RAYMO connector ?
  • Easy mating, can be blind-mated guiding mechanism ensures precise alignment
  • Proven Rugged, Lightweight,and Compact Solutions
  • Long prct durability 5,000 mating cycles guaranteed
  • 360° EMC shielded preventing electromagnetic interferences
  • Functional in a wide temperature range from -65°C to +200°C
  • Help you save at least 50% cost
  • Fast delivery: 2-15 working days
  • Cable assembly offer, help you save prction time

Compatible Straight Circular Push Pull Connectors High Reliability For OD 4.2-5.2mm Cable

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
