Description
IP40 Cicular connector M16 Bayonet locking system 678 Series male cable connector
  • RM-M16 series Bayonet Miniature 678 Series male cable connector, Bayonet locking system , cable to cable connector
  • can be 100% compatible with binder 678 series
  • RoHS 2.0
Main Features
  • Cable Connectors
  • Bayonet locking system
  • 2 – 24 contacts
  • Degree of protection IP40
  • Solder termination
  • Diameter 19.9 – 20 mm
  • Touch-proof plastic housing

Material


Shell body PA66
Insulating body PBT
Contact pin CuZn, silver-plated and flash goldplated
Sleeve PC
Bend protection sleeve TPE
Screw steel Nickel-plated


Electrical data

Wire gauge max, 0.75mm²(max. AWG 20) ( 3-8 poles)
max, 025mm²(max. AWG 24) (12 poles )
Cable outlet 3-6mm/6-8mm
Mechanical opera >500 ma
Upper temperature + 85 °C
Lower temperature – 40 °C
Rated voltage 250 V (32 V) 2-4 poles
60 V (32 V) 5 poles
250 V (32 V) 6poles
125V (32 V) 7poles
60 V (32 V), 8-12poles
Rated impulse voltage 1500V 2-6poles
800V 7 poles
500V (32 V)8-12poles
Rated current (40 °C) 7A 2-3 poles
6A 4-6 poles
5A 7-8poles
3A 12poles
Contact resistance ≤ 5 MΩ 3-8 poles
　 ≤ 3 mΩ 12poles
