Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut
Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut
Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut
Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut
Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut
Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut
Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut
Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut
Specifications
Brand Name :
MOCO
Model Number :
SS 103
Certification :
UL / CE / RoHs / ISO9001
Place of Origin :
Shenzhen. China
MOQ :
10pcs
Payment Terms :
T/T, Paypal, Western Union
Supply Ability :
200000pcs/month
Delivery Time :
7-10 work days after simple confirmation
Packaging Details :
Each connector in a PE bag. every 50 or 100 pcs of connectors in a small box (size:20cm*15cm*6cm), every 6 small boxes in a carton(size:30cm*20cm*20cm)
Product Name :
SS 103 4 pin brass short type male straight plug with nut for overmolding
pin :
4 pin
gender :
male
insulator material :
PPS
Endurance (Shell) :
5000 mating cycles
Material :
Chrome Plated Brass
Description

SS 103 4 pin brass short type male straight plug with nut for overmolding

Main features:

- Security of the push pull self locking system for easy and quick operation;

- Solder or PCB contacts( Straight or elbow);

- High sealing for underwater application, up to IP68;

- Half-shell key to avoid cross mating;

- Vacuum-tight socket suitable for vacuum equipment.

Description:

T7 is a short type straight plug with half - shell key, cable collect and nut for overmolding.

Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut

Dimensions:

MOCO P / N T7
Configuration Brass (gold plated)
Insulator PPS
Endurance (Shell) 5000 mating cycles
Temp (min) -40 deg
Temp (max) 200 deg C
Humidity (max) <=95% [at 60 deg C / 140 F]
Vibration 15 g [10 Hz - 2000 Hz]
Shock Resistance 100 g [ 6 ms]
Salt Spray Corrosion >144 hr
IP Rating 68
Shielding (min) 75 dB (10 MHz)
P op (max) 60 bar (870 psi)

Brass Short Type Circular 4 Pin Connector , Male Straight Plug Connector With Nut

We also provide cable assembly service!

If you have any interests, please feel free to contact us!

Contact us today, we are looking forward to serving you!
