High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
High Strength Aluminium Clad Sheet , Aluminum Clad Steel Coil Multipurpose
Specifications
Brand Name :
ZEGOTA
Model Number :
ACSS12
Certification :
ISO9001:2008 , IATF/TS16949:2016 , ISO14001:2004 , CNAS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
Thin Film, Rustproof Paper
Delivery Time :
10-15 Days
Payment Terms :
100% T/T Before Shipment
Supply Ability :
100000 Tons Per Year
Product name :
Aluminum clad stainless steel
Material :
Aluminum + Stainless steel
Application :
energy management, 3C industry ，cooling industry
Feature :
Ultra-thin composite, corrosion resistance, high strength
Function :
Easy to process, light weight, high combination rate
Shape :
Strip , coil , sheet
Description

Ultra thin aluminum clad steel clad aluminum with corrosion resistance and high strength

Aluminum clad stainless steel material is a combination of metal and steel products. With high strength, easy to process and other advantages. ZEGOTA uses new technology, high-grade equipment and high quality raw materials to research and produce high quality aluminum clad stainless steel materials with superior performance.

Advantages:

1. Easy processing: aluminum has good cutting performance. Through the combination of the two, the perfect surface quality and strength of stainless steel can be obtained at the same time, the cutting efficiency can be greatly improved.

2. High strength: stainless steel has high strength, while aluminum is softer. Combine the two and make full use of their advantages to compound a special material.

3. Corrosion resistance: stainless steel has corrosion resistance characteristics. When combined with aluminum, it can form a kind of corrosion resistant composite material.

Application:

1. Energy management: for the rapidly developing new energy vehicles, the aluminum stainless steel composite material not only protects the battery, but also provides excellent heat dissipation performance.

2. 3C industry: the back plate of mobile phone is made of aluminum stainless steel composite material, which has the advantages of beautiful surface, anti-fall, anti-scratch and good thermal conductivity.

3. Cooling industry: aluminum stainless steel composite material not only guarantees cooling effect, but also provides high strength, which brings qualitative changes to product design.

Parameter:

Clad material Stainless Steel Stainless Steel Aluminum Aluminum Stainless Steel
Aluminum Aluminum Stainless Steel Stainless Steel Aluminum
Stainless Steel / / Aluminum /
Thickness(mm) 0.01-4.0 0.01-4.0 0.01-4.0 0.01-4.0 0.01-4.0
Width(mm) 5.0-1500 5.0-1500 5.0-1500 5.0-1500 5.0-1500
Tensile strength(MPa) 600-780 250-310 400-480 230-320 400-480
Yield strength(MPa) 540-700 180-250 340-400 190-280 340-400
Elongation(%) ≥10 ≥25 ≥20 ≥25 ≥10
