Glass Fiber Media Mini HEPA Filter Leak Proof Special Aluminum Foil As Separator
Glass Fiber Media Mini HEPA Filter Leak Proof Special Aluminum Foil As Separator
Glass Fiber Media Mini HEPA Filter Leak Proof Special Aluminum Foil As Separator
Glass Fiber Media Mini HEPA Filter Leak Proof Special Aluminum Foil As Separator
Specifications
Brand Name :
indair
Model Number :
ID-HT-05
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1
Price :
negotiable
Supply Ability :
1000 unit per day
Packaging Details :
carton with plastic bag
Media :
special glass fiber
Frame :
sus 304
Final pressure drop :
500 pa
Efficiency :
H13, H14
Temperature :
150°C 250°C 300°C 350°C
SIZE :
customization
Description

350℃ Heat-Resistant High Temperature HEPA deep pleated separator Air Filter H14

Features

1, Frame: Galvanized frame,stainless steel frame.

2, Media: using special glass fiber filter paper as the filter material, high dust-holding capacity, low initial resistance.

3, Using special aluminum foil as separator.

4, Efficiency(EN779:2002 filter class)H10,H12,H13,H14

5, (ASHRAE:52.2:2007 filter class)MERV16, MERV17, MERV18, MERV19.

6, Each filter is through rigorous testing.

7, Recommended final pressure drop:450pa.

8, Temperature:350

9, Fire rating :DIN 53438 class F1.

Applications

Mainly used for the requirements of the electronics industry, coating industry,chemical industry high-temperature air purification equipment and system.

• High temperature
• High mechanical strength
• High efficiency
• High air volume		 Recommended final pressure drop: 500 Pa.
Temperature:150°C 250°C 300°C 350°C.


We not only produce all kinds of different normal size High temperature resistance Separator HEPA filter,but also accept all kinds of customized
size High temperature resistance Separator HEPA filter.Please choose what size you want to buy refer to the below table,

Model

Width

(mm)

Height

(mm)

Depth

(mm)

Air flow

(m³/h)

Initial

Resistance

(≤pa)

Fianl Resistance

(pa)

Medial

Area

(s.q.m)

Dust

Holding

(g)

Efficiency
K84-001 484 484 120 390 200 400-600 4.4 230 H13~H14
K84-002 610 610 120 620 200 400-600 7.1 370 H13~H14
K84-003 915 610 120 930 200 400-600 10.6 560 H13~H14
K84-004 1220 610 120 1500 200 400-600 14.1 740 H13~H14
K84-005 484 484 150 530 200 400-600 6.0 320 H13~H14
K84-006 610 610 150 1000 200 400-600 9.7 510 H13~H14
K84-007 915 610 150 1500 200 400-600 14.5 770 H13~H14
K84-008 1220 610 150 2000 200 400-600 19.3 1020 H13~H14
K84-009 484 484 220 1000 200 400-600 9.8 600 H13~H14
K84-010 610 610 220 1600 200 400-600 15.8 920 H13~H14
K84-011 915 610 220 2300 200 400-600 23.7 1340 H13~H14
K84-012 1220 610 220 3000 200 400-600 31.6 1750 H13~H14
