Pharmaceutical Industry Cleanroom Air Shower Coated Cold Rolled Steel Low Noise
Pharmaceutical Industry Cleanroom Air Shower Coated Cold Rolled Steel Low Noise
Pharmaceutical Industry Cleanroom Air Shower Coated Cold Rolled Steel Low Noise
Pharmaceutical Industry Cleanroom Air Shower Coated Cold Rolled Steel Low Noise
Specifications
Brand Name :
INDAIR
Model Number :
ID-AS(2)-04
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1
Price :
negotiable
Supply Ability :
500 units per days
Delivery Time :
15 work days
Packaging Details :
wooden case with carton
Material :
coated cold rolled steel
Power :
3.6kw
Control panel :
LCD display, PLC control system
Noise :
＜62 db
Door :
Interlock Door,Adjustable Time
HEPA :
H13,H14
Description

SS 304 Pharmaceutical Industry HEPA filter Class 100 powder coated steel air shower with nozzles

Characteristics:

This is a kind of local purifying equipment, fixed on the partition between clean room and unclean room. It is used for shower and removing dust when personnel or objects entering into clean area. Effectively reduce dust source from entering into clean area after used, and keep clean area in normal working state. Shower way: single-side shower, double-side shower, three-side shower, top shower

Main characters:

1. Automatic control operation with interlock design, the system is equipped with photoelectric sensor.
2. Whole room is made of cool rolling stell plate,the surface is static electricity spray-plastic coated.
3. Door,baseplate,nozzle are made of stainless steel with beautiful design, easy to clean and abrasion resistant
4. Modularized design,more convenient for transport and assembling.
5. Shower time is adjustable from 0 to 99 seconds.
6. Equipped with pre-filter and deep-filter system.
7. Wind speed of nozzle port can reach 25m/s. it can reach 18m/s when blowing on human body.
8. EVA sealing material makes great sealing performance.
9. We can customize the shower room body material and dimension according to different
customer requirements.



Type: Double Person SUS304 Air Shower
˙ Outside Dimension (mm):1400W×1000D ×2100H
˙ Dimension of Air Shower Area (mm):800W×900D×1960H
˙ Applicable Number of People:1 person
˙ Materials: All Full Set Stainless SUS304 or coated cold rolled steel
˙ Number of Nozzle:12(Two Sides) Stainless Steel 304
˙ Mouth Diameter of Nozzle:Φ30mm
˙ Control panel:sus304 frame,LCD display, PLC control system
˙ Speed of Air Flow at the Nozzle:>28m/s
˙ Dimension of High Efficiency Air Filter (mm):600×600 ×120
˙ Lock:Electronic Interlock,two door can't open at the same time.
˙ Pre-Filter:600*350*10(mm),2PCs,synthetic fiber with aluminum
˙ HEPA Filter:2PCs,600*600*120(mm),
˙ FAN:2PCs,Power:0.55KW, Air Volume:1000/PCS,Air Pressure:1200Pa
˙ LAMP:1PCs LED light,Power:1*7W.
˙ Shower Time:0-99s adjustment
˙ HEPA Filter Efficiency:H13,99.995%@0.38um.
˙ Maximum Power Consumption:1.1KW
˙ Voltage ˙available:380VAC / 5Phase,50HZ(can make other standard voltage)

Model ASS Single Person ASD Double Person
HEPA H13,H14
Air Velocity(m/s) ≥25
Number of Nozzle 16 32
Power Supply AC380V/3P/50Hz
Power 1.8KW 3.6KW
Box Material High-grade steel with stoving varnish;SUS304
Floor Material High-grade steel with stoving varnish,SUS304 on the passageway
Door Interlock Door,Adjustable Time

External Dimension

W*H*D(mm)

 1200*1000*2100 1200*2000*2100
Internal Dimension(mm) 800*900*1960 800*1900*1960
Products Standard Q/320507 LDH012-2016
